4 English

is used in the range up to 70 m. For outdoor application.

3. Compensator for fast leveling is used in the range up to ±3°.

4. Warning sound is prodced when the instrument inclines from horizontal

plane more than ±3°.

5. Rotating fine adjustment mechanism makes it easy to find objects.

6. Built-in locking system automatically locks the compensator when the power

is OFF. It protects the compensator from vibrations during transportation.

7. Intermediate position of the switch handle activates slope mode.

FEATURES

1 Battery compartment

(rechargeable battery compartment)

2 Switch On handle (compensator lock)

3 Vertical laser window

4 Horizontal laser window

5 Fine adjustment screw

6 Adjusting legs

7 Bubble level

OPERATION

1. Open battery compartment cover. Insert 4 batteries with proper polarity

into the holder. Contacts of the holder (batteries) or Li-batteries must coincide

with contacts of the battery compartment. Close the battery cover.

2. Place the instrument on the tripod or floor. When using tripod, place the

instrument on the tripod and screw the centering screw into the center hole.

3. Switch On the instrument by rotating the switch 2 counterclockwise until

KEYPAD

1 On/shift/O button for

V emitters

2 ON/OFF indicator

3 Detector button (D)

4 Detector mode indicator
