5English

its clicking position. Green LED will flash. If the battery power is low, green

LED will flash. If the battery power is low, green color of the indicator will

be changed into red.

4. The instrument works in slope mode in the first position of the switch

(X). It is possible to project laser lines at any angle. In the position ON the

pendulum will be unlocked and laser lines will be automatically self-leveled.

5. If there is a sound signal and laser lines begin to blink while switching on

the instrument, that means that the instrument is out of range more than

±3°. Adjust the position of the instrument by means of the bubble level with

the help of legs or tripod.

6. Aim the down point on the required point on the floor. Rotate the upper

part of the instrument to adjust vertical lines. Then adjust the position of

the instrument with the help of fine adjustment screw.

7. Line laser has several operating modes. Press button 1 to select laser lines.

Variants of projections: - horizontal beam and down point;- horizontal beam

and vertical beam, down point; - horizontal beam and 3 vertical beams, down

point. - orizontal beam and 4 vertical beams, down point.

DETECTOR (IS NOT SUPPLIED WITH THE LINE LASER)

1. On/Off button

2. Signal LEDs

3. Bubble level

4. Sensitive element

5. Sound Off button

6. Clamp on the staff

7. Dynamic loudspeaker

APPLICATION OF THE DETECTOR

Application of the detector is a decisive advantage when working outside in

sunny weather. Press button (3) to switch on the detector mode. Open the

battery cover and insert the battery into the detector. Press On/O button

to switch on the detector. Bring the receiver to the place of beam location.

When laser beam will be on the sensitive element, there will be sound
