4 English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Cube 2-360 is a reliable and convenient line laser. It will be irreplaceable

tool for many years. Place the line laser on the working surface or x it

on the tripod/rod or wall mount (depends on the complete set). Set the

compensator switch (5) into the position ON. Two laser beams will be ON.

If the switch (5) is in the position ON, the tool is switched ON and the com-

pensator works. Visual alarm (blinking lines) and sound alarm inform that

the tool is out of the compensation range ±4º. Align the line laser in the

horizontal plane.

Intermediate position of the switch (5) indicates that the tool is ON, but

the compensator is locked. And there is no warning when the tool is in tilt

position. If the switch (5) is OFF, that means that the tool is switched OFF

and the compensator is locked. Press button (1) once – horizontal beam

is ON. Press button (1) once again – vertical beam is ON. Press button (1)

once again – vertical and horizontal beams are ON. Press button (2) once.

Outdoor mode is activated. Press button (2) once again. The line laser be-

gins to work in indoor mode.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Place the line laser on the tripod 5m away from the wall so the horizontal

laser line will be directed to the wall. Switch on the power. The line laser

starts to self-level. Mark point A on the wall to show the contact of laser

beam with the wall. Turn the line laser by 90° and mark points В, С, D

on the wall. Measure distance “h” between the highest and lowest points

(these are A and D points in the picture). If “h” is ≤ 6 mm, the line laser

accuracy is good. If “h” exceeds 6 mm, apply service center.
