the instrument unattended while using charger. Parameters of the

charger must correspond to the parameters of domestic electricity.

Output voltage must be no more than 5V.

2. Set the compensator locking grip (5) into ON position. Horizontal beam is ON.

If the switch is ON, that means the power is on and the compensator is working.

If the switch (5) is in intermediate position, that means the power is opened,the

compensation is still locked, but it will not warn if you issue the slope. It’s

the hand-mode. If the switch (5) is OFF, that means that the instrument is

o, the compensator is also locked.

3. Press button (1) to switch the vertical and horizontal beams on. Press

button (1) once again to switch 2 vertical beam son. Press button (1) to switch

the horizontal and vertical beams on. Switch on only necessary laser lines

in order to save battery life.

4. Press button (2). The mode “outside” is activated. Press button (2) once

again. The tool begins to operate in “inside” mode. Use the detector of laser

beam for this mode. See the operating manual for the operation with detector.

TO CHECK THE ACCURACY

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Place line laser on the tripod 5m away from the wall so the horizontal laser

line will be directed to the wall. Switch on the power. The line laser starts

to self-level. Mark point A on the wall to show the contact of laser beam

with the wall. Turn the line laser by 90° and mark points В, С, D on the wall.

Measure distance “h” between the highest and lowest points (these are A

and D points in the picture). If “h”is ≤ 6 mm, the measurement accuracy is

good. If “h” exceeds 6 mm, apply service center.

TO CHECK PLUMB

Choose a wall and set laser 5m away from the wall. Mark point A on the

wall, please note the distance from point A to ground should be 3m. Hang

a plumb line from A point to ground and nd a plumb point B on ground.

turn on the laser and make the vertical laser line meet the point B, along
