Omperator's anual

- 7 -

2. Technical pecificationss

3. Start-up and use

-C .

-.3

Fit the wheels and foot (or the caster wheel for models that are fitted with this) according to the

instructions provided in the packaging. For versions with fixed feet, assemble the front bracket kit or

the vibration-dampers if furnished. Check that the rating data match the effective characteristics of

the system (voltage and power).

Check for correspondence between the compressor plate data with the actual specifications of the

electrical system.Avariation of ± 10% with respect of the rated value is allowed.

Insert the power plug in a suitable socket checking that the button of the pressure switch located on

the compressor is in the “O” (OFF) position (fig ).

heck the oil level using the rod included in the oil fuel plug (fig 7a-7b-7c) or the sight glass (fig. 7d),

and if necessary top up.

At this point, the compressor is ready for use.

Operating on the switch of the pressure switch (fig ), the compressor starts, pumping air in the

reservoir through the delivery hose.

The absence of pressure in the head facilitates subsequent restart. When air is used, the

compressor restarts automatically when the lower calibration value is reached (approx. 2 bar

between upper and lower). The pressure inside the reservoir can be checked on the gauge

provided (fig. ).

The manufacturer reserves himself the right to make the manual's content or function change

without any preliminary notification of the users.

FC 230/24 CM2 FC 230/50 CM2

Power, kW

1,5 1,5

Tank, l

24 50

Pressure, bar

Air displacement, l/min

230 230

RPM

2850 2850

Volt/Hz

220/50 220/50

Size, mm

620х280х600 730х320х650

Weight, kg

22 31

MODEL
