Technical specifications

Type HD 4/9 P HD 4/9 P HD 5/11 P

GB KAP SA

Main Supply

Voltage V 110 120 220

Current type Hz 50 60

Connected load kW 1,4 1,3 2,0

Protection (slow, char. C) A 15 13

Type of protection -- IPX5

Extension cable, max. 30 m

(Protection class 1)

2,5

Water connection

Max. feed temperature °C 60

Min. feed volume I/min 9,5 12

Suck height from open container (20 °C) m 0,5

Max. feed pressure MPa 1

Performance data

Operating pressure of water (using standard

nozzle)

MPa 9 11

Size of standard nozzle -- 030 036

Max. operating over-pressure MPa 12 13 16,5

Water flow rate I/min 6,5 6,2 8,0

Max. recoil force of trigger gun N 14,76 20,4

Values determined as per EN 60335-2-79

Hand-arm vibration value m/s

<2,5 2,1 3,2

Uncertainty K m/s

0,6 0,7 0,8

Sound pressure level L

dB(A) 70 69 73

Uncertainty K

dB(A) 3

Sound power level L

+ Uncertainty K

dB(A) 85 85 89

Dimensions and weights

Length mm 351

Width mm 312

Height mm 904

Typical operating weight kg 21,6 20,5 21,0

20 EN
