– 9

Type HD 5/11 P HD 5/11 P HD 5/11 P

Main Supply

Voltage V 230 220 230...240

Current type Hz 50

Connected load kW 2,2

Protection (slow, char. C) A 10

Type of protection -- IPX5

Extension cable, max. 30 m

(Protection class 1)

2,5

Water connection

Max. feed temperature °C 60

Min. feed volume I/min 12

Suck height from open container (20 °C) m 0,5

Max. feed pressure MPa 1

Performance data

Operating pressure of water (using standard

nozzle)

MPa 11

Size of standard nozzle -- 036

Max. operating over-pressure MPa 16

Water flow rate I/min 8,1

Max. recoil force of trigger gun N 20,4

Values determined as per EN 60335-2-79

Hand-arm vibration value m/s

2,7

Uncertainty K m/s

0,8

Sound pressure level L

dB(A) 73

Uncertainty K

dB(A) 3

Sound power level L

+ Uncertainty K

dB(A) 89

Dimensions and weights

Length mm 351

Width mm 312

Height mm 904

Typical operating weight kg 20,5

21EN
