23
PowerPainter 90 EXTRA
GB
i
The values in the table are reference values.
Find out how much the paint needs to be thinned by testing it. Details on how to test the spray paint can be found
in the section called "Spray Technique".
Assembly
1. Screw the paint container holder to the basic unit using the two screws. (Fig. 2)
2. Insert the hose holder into the telescopic handle. (Fig. 3)
3. Remove the protective covers on the hose and hose connection. (Fig. 4)
4. Screw the pressure gauge to the hose connection.
5.
Screw the high pressure hose onto the pressure gauge.
Keep hold of the connection using an adjustable spanner and tighten the hose connection with another spanner. (Fig. 5)
6. Screw the thread at the other end of the hose to the spray gun connection. Keep hold of the spray gun by applying an adjustable
spanner to the handle and tighten the hose nut using another spanner. (Fig. 6)
7. Place the nozzle holder on the spray gun (Fig. 7A ) and rotate it into the nal position (Fig. 7B), in order to x it.
8. Pull the red shutter out of the paint entry point. (Fig. 8, 1)
9. Connect the suction hose to the paint entry point and secure into position. (Fig. 8)
10. Push the return line on to the return ow connector. (Fig. 9)
Control elements on the device (Fig. 10)
A The ON/OFF switch turns the power to the sprayer on and o (0=OFF, l=ON).
B The following settings can be made with the selector switch:
PRIME (Switch set vertically)
•
For prelling the system with paint
•
For pressure relief
SPRAY (Switch set horizontally)
•
For using the spray gun
C The pressure of the spray is set by the pressure regulator.
The correct spray pressure depends on the paint being used.
Telescopic handle
The telescopic handle can be extended or retracted:
To unlock the telescopic handle:
Turn the locknut (g. 11, 1) in an anti-clockwise direction
To lock the telescopic handle:
Turn the locknut (g. 11, 1) in a clockwise direction
Spray Gun
Danger
Always lock the trigger o when attaching the spray nozzle or when the spray gun is not in use.
•
To lock the trigger, push in the trigger lock from left to right, when looking at the rear of the gun. (Fig. 12, A)
•
To unlock the trigger, push the trigger lock from right to left, when looking at the rear of the gun. (Fig. 12, B)
•
Insert the nozzle with the tip pointing forwards. (Fig. 13)
i
Another nozzle size and gun lter must be used, depending on the material to be processed.
Information about all the available nozzles and lters can be found in the section about "Accessories".
Pressure Relief Procedure
Danger
Be sure to follow the Pressure Relief Procedure when shutting the unit o for any purpose.
This procedure relieves the pressure from the spray hose and the gun.
1. Secure the spray gun. (Fig. 12)
2.
Switch the device o.
Turn the switch into the PRIME position (vertical). (Fig. 14)
3. Release the spray gun. Hold the spray gun over an empty container and press the trigger to relieve the pressure.
