ПАНЕЛЬ УПРАВЛЕНИЯ

4. USE OF THE COOKER HOOD

4.1. CONTROL PANEL

4.1.1. TOUCH CONTROL PANEL

1 2 3 4 5 6 7

1. Motor on / off. It is used to start and stop the motor of the cooker hood.

2. Reducing the speed. Used to reduce motor speed while the cooker hood is in operating state.

3. Display. Information on the operating status of the cooker hood is read. The aluminum filter should be

cleaned when the C mark appears. To clear the C warning, the speed reduction button numbered 2 should

be pressed for 5 seconds while the device is off.

4. Increasing the speed. Used to increase the motor speed while the cooker hood is in operating state.

5. Timer. It is used for automatic turn-off of the cooker hood after 15 minutes. Ventilation mode is activated

when it is pressed for 3 seconds. The screen will be rotating and the cooker hood will operate to ventilate the

ambient in the speed 1 for 10 minutes on hourly for 24 hours. To deactivate, it should be pressed on the

same button for 3 seconds or the cooker hood is turned off by pressing the motor turn on/off button

numbered 1.

6. Turn on / off the lamp. It is used to turn on and off the cooker lightings.

7. Remote control sensor.

4.1.2. TOUCH CONTROL PANEL 3-SPEED

1 2 3 4

1. Turning on/off the motor in speed 1. It is used to start and stop the motor of the cooker hood in speed 1.

2. Turning on/off the motor in speed 2. It is used to start and stop the motor of the cooker hood in speed 2.

3. Turning on/off the motor in speed 3. It is used to start and stop the motor of the cooker hood in speed 3.

4. Turn on / off the lamp. It is used to turn on and off the cooker lightings.

Timer: It is used for automatic turn-off of the cooker hood after 15 minutes. Timer mode is activated when

the desired speed is pressed for 3 seconds. The button light will blink.

4.1.3. CONTROL PANEL OF MECHANICAL PUSH BUTTON

1 2 3 4 5

1. Switch off the motor. It is used to stop the motor of the cookerhood.

2. 1st cycle. It is used to operate the motor of the cookerhood in 1st cycle.

3. 2nd cycle. It is used to operate the motor of the cookerhood in 2nd cycle.

4. 3rd cycle.It is used to operate the motor of the cookerhood in 3rd cycle.

5. Turn on/off the lamp. It is used to turn on and off the cooker lights.

4.2. USAGE OF THE COOKER HOOD

Your device has been manufactured in a suitable way for use with chimney and without chimney.

4.2.1. USE WITH CHIMNEY

Your device should be connected to a chimney in the room so that it will be able to discharge the indoor air to

outer environment. The minimum Ø120mm air escape pipe should be used. For your device to operate more

efficiently, an air escape pipe that is as short possible and having few elbows should be used.

If your device is fitted with a carbon filter, it has to be removed.

1) Вкл/Выкл первой скорости.

2) Вкл/Выкл второй скорости.

3) Вкл/Выкл третьей скорости.

4) Кнопка освещения.

Включение / выключение освещения.

ТАЙМЕР

Вытяжка оборудована таймером. Таймер активируется при нажатии более 3 секунд на кнопку

выбранной скорости. Индикатор начнет мигать, что сигнализирует об активации таймера.

По истечении 15 минут работы на выбранной скорости мотор и освещение автоматически

отключаются.
