12 ENGLISH

Adjusting the cutting angle

CAUTION: Always be sure that the tool is

switched o󰀨 before folding or unfolding the head.

CAUTION: When folding the head for carrying

the tool or after using the tool, be sure to attach

the blade cover before folding the head.

CAUTION: When folding the head, be careful

not to pinch your ngers between the head and

the tool body.

Theangleoftheheadcanbeadjustedin10steps.To

change the angle of the head, follow the steps below.

1. Holdtheheadandthetoolbodyasshowninthe

gure.

►Fig.5: 1. Head 2.Angleadjustmentbutton

2. Adjusttheangleoftheheadwhileholdingdown

theangleadjustmentbutton,andthenreleasetheangle

adjustmentbutton.

3. Movetheheadslightlyuntilitislockedwithaclick.

NOTE:Makesurethattheheadissecurelylocked

before operating the tool.

Adjusting the pipe length

CAUTION: Always be sure that the tool is

switched o󰀨 before adjusting the pipe length.

CAUTION: When adjusting the pipe length,

be sure to attach the blade cover before adjusting

the pipe length.

CAUTION: When adjusting the pipe length, be

careful not to pinch your ngers.

CAUTION: Make sure that the lock-lever is

locked securely.

Loosenthelock-lever,thenadjustthelengthofthepipe,

and then lock the lock-lever.

►Fig.6: 1. Lock-lever

Adjusting the front grip position

CAUTION: Always be sure that the tool is

switched o󰀨 before adjusting the position of the

front grip.

CAUTION: When adjusting the position of the

front grip, be careful not to pinch your ngers.

CAUTION: Make sure that the thumb nut is

tightened securely.

CAUTION: Do not move the front grip beyond

the arrow mark.

Toadjustthepositionofthefrontgrip,loosenthethumb

nutbyturningitcounterclockwise,thenadjusttheposi-

tionofthefrontgrip,andthentightenthethumbnutby

turning it clockwise.

►Fig.7: 1. Thumb nut 2. Arrow mark

ASSEMBLY

CAUTION: Always be sure that the tool is

switched o󰀨 and the battery cartridge is removed

before carrying out any work on the tool.

CAUTION: When replacing the shear blades,

always wear gloves so that your hands do not

directly contact the blades.

Installing or removing the shear

blades

CAUTION: Attach the blade cover before

removing or installing the shear blades.

NOTICE: When replacing the shear blades, do

not wipe o󰀨 grease from the gear and crank.

NOTE: Before installing or removing the shear

blades, unfold the head of the tool so that the head is

straighttothetoolbody.

1. Place the tool upside down.

2. Remove 4 screws with a screwdriver and remove

the shear blades.

►Fig.8: 1. Screw

3. Remove the crank from the shear blades.

►Fig.9: 1. Crank

NOTE:Thecrankmayremaininthetool.

4. Prepare the crank and new shear blades.

►Fig.10: 1. Crank 2. Shear blades

5. Remove the blade cover, and then attach it to the

new shear blades.

6. Applyasmallamountofgreasetotheperipheryof

the crank. Attach the washer, gear, and the crank to the

pin in order.

►Fig.11: 1. Crank 2. Gear 3. Washer 4. Pin

7. Adjustthecranksothatthe2smallholesonthe

crank are lined up on the alignment line as shown in the

gure.

►Fig.12: 1. Alignment line 2. Small hole

8. Slide the shear blades so that the hole on the

guide plate is positioned at the center of the rings of

blades.

►Fig.13: 1. Guide plate

9. Insert the screw removed in step 2 into the hole on

the shear blades through the hole on the blade cover.

►Fig.14: 1. Hole

10. Attach the shear blades to the tool, and then

tighten 3 screws with the screwdriver.

►Fig.15: 1. Screw

11. Remove the screw inserted into the hole on the

shearbladesinstep9,andthentightenittoxthe

shear blades.
