English | 25

Digital laser measure GLM 40

Protection rating IP 54 (dust and

splash-proof)

Batteries

Rechargeable batteries

2 x 1.5 V LR03 (AAA)

2 x 1.2 V HR03 (AAA)

Individual measurements per set of batteries 5000

Unit of measurement setting m, ft, in

Sound setting ●

A) For measurements from the rear edge of the measuring tool, applies to high reflectivity of the

target (e.g. a white-painted wall), weak backlighting and 25°C operating temperature. In addi-

tion, a deviation influence of ± 0.05mm/m needs to be taken into account.

B) For measurements from the rear edge of the measuring tool, applies to low reflectivity of the tar-

get (e.g. black cardboard), strong backlighting and -10°C to +45°C operating temperature. In

addition, a deviation influence of ± 0.15mm/m needs to be taken into account.

C) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by

condensation is expected.

D) The width of the laser line depends on the surface characteristics and on the ambient condi-

tions.

E) Except battery compartment

The serial number (9) on the type plate is used to clearly identify your measuring tool.

Fitting

Inserting/Changing the Batteries

It is recommended that you use alkaline manganese or rechargeable batteries to operate

the measuring tool.

With 1.2 V batteries fewer measurements could be possible than with 1.5 V batteries.

Press the locking mechanism (8) to open the battery compartment cover (7) and re-

move the battery compartment cover. Insert the batteries. When inserting, pay attention

to the correct polarity according to the representation on the inside of the battery com-

partment.

If the battery symbol appears on the display for the first time, at least another 100 in-

dividual measurements are possible. When the battery symbol flashes, you have to re-

place the batteries because measurements are no longer possible.

Always replace all the batteries at the same time. Only use batteries from the same man-

ufacturer and which have the same capacity.
