28 | English

can, for example, move the required distance away from the wall while reading off the

current distance at all times.

For length measurements, repeatedly press button (4)[Func] until the indicator for con-

tinuous measurement appears on the display(1).

To switch on the laser beam, briefly press the measuring button (2)[ ].

Move the measuring tool until the desired distance is shown at the bottom of the display.

Briefly press the measuring button (2)[ ] to end continuous meas-

urement. The last measured value will be shown at the bottom of the

display.

Continuous measurement automatically switches off after

fiveminutes.

Area measurement

For area measurements, repeatedly press button (4)[Func] until the indicator for area

measurement appears on the display(1).

Then measure the width and length one after the other as with a length measurement.

The laser beam remains switched on between the two measurements. The distance to be

measured flashes in the indicator for area measurement .

The first measured value is shown at the top of the display.

After the second measurement has been completed, the area will be

automatically calculated and displayed. The end result is shown at

the bottom of the display, while the individual measured values are

shown above it.

Volume measurement

For volume measurements, repeatedly press button (4)[Func] until the indicator for

volume measurement appears on the display(1).

Then measure the width, length and depth one after the other as with a length measure-

ment. The laser beam remains switched on between the three measurements. The dis-

tance to be measured flashes in the indicator for volume measurement .

The first measured value is shown at the top of the display, while the

second measured value is shown below it. After the third measure-

ment has been completed, the calculated area from the two previous

measurements will be displayed at the top of the display.

The end result of the volume measurement is shown at the bottom of

the display, while the last measured value is shown above it.

1 609 92A 5DX | (27.01.2020) Bosch Power Tools
