User manual
LASER DISTANCE METER
6
EN
XP3 PRO CONDTROL
7
User manual
LASER DISTANCE METER
EN
XP3 PRO CONDTROL
Congratulations on your purchase of laser distance meter XP3 PRO CONDTROL.
Safety instructions can be found in the end of this user manual and should be
carefully read before you use the product for the first time.
INTENDED USE
Laser distance meter XP3 PRO is intended to measure distance, to stake out a line,
to calculate area and volume of measured objects as well as perform calculations
by tilt sensor and Pythagoras’ Theorem and able to transmit measuring results
via Bluetooth. The product is suitable for use at both indoor and outdoor building
areas.
DELIVERY SET
The delivery set of XP3 PRO includes:
1. Laser distance meter – 1pc.
2. Carry pouch with a strap - 1 pc.
3. User manual - 1 pc.
4. Batteries (type AAA) - 3 pcs.
5. USB charger - 1 pc.
TECHNICAL SPECIFICATIONS
Working range* 0,05– 120 m*
Measuring accuracy ** ± 1,5 mm**
Smallest unit displayed 1 mm
Display backlight +
Reference point setting +
Continuous measurement (tracking) +
Max./min. value +
Addition/subtraction +
Area/wall area/volume +
Calculation of horizontal distance by tilt sensor +
Calculations by Pythagoras’ Theorem +
Stake-out function +
Timer +
Bluetooth +
Internal memory +
Laser Class II, 635 nm, <1 mW
Working temperature –10 °С ... +50 °С
Storage temperature –20 °С ... +60 °С
Dust and water protection IP54
Dimensions 136х59х28 mm
Weight 170 g
Power supply
3 х battery AAA 800 mAh
1.2V Ni-MH
* Use a reflector to increase the measurement range during daylight or if the
target has poor reflection properties.
** Accuracy can decrease in unfavorable conditions, such as intense sunshine or
when measurements are made against glossy or transparent surfaces, moving
objects, objects with rough surface.
In unfavourable conditions or when measured distance is over 100 m the
maximum permissible accuracy is calculated in the following way:
± (Y + 0,25хDх10-3) mm, where
D (mm) - measured distance
Y (mm) - permissible accuracy according to technical data.
