Levenhuk LX700/LX1000/LX1500 Hunting Laser

Rangender

Please carefully read the safety instructions and the user manual before using this product, otherwise it may result in

hazardous laser radiation and electric shock. Use the device only as specied in the user manual. Keep away from children.

LCD Display

1. Low battery indicator

2. Angle icon

3. Current angle value

4. Center of the target (bullseye)

5. Flagpole lock mode

6. Distance measurement mode

7. Straight line distance

8. Units of measurement

9. Trajectory adjustment icon

10. Trajectory adjustment value

11. Speed icon

Getting started

• Charging the device. Connect the power cable to the device and the DC adapter via a USB plug and connect it to the AC power

supply. Charging voltage and current: 5V, 1A.

• Press the POWER/MEASURE button to turn the device on or o. The rangender enters the distance measurement mode by default

(Fig. 1).

Figure 1

• Rotate the focusing ring until the view is in focus.

• Press and hold the MODE button to change the measurement units. Quickly press this button to choose between the modes.

There are 5 modes available: 1) distance measurement mode, 2) slope mode, 3) horizontal distance mode, 4) height distance

mode, and 5) speed mode.

Using

Distance measurement mode

In the distance measurement mode, aim the device at your intended target and press the POWER/MEASURE button. The distance

value will be displayed (Fig. 2).

Figure 2

Press and hold the POWER/MEASURE button for continuous measurement.

Note: The maximum measurement range is aected by weather conditions as well as the dimensions and reectivity of the target

object.
