English | 11

Cross line laser Quigo Green

Operating time at least

3h

Weight according to EPTA-Procedure01:2014

– Cross line laser 0.27kg

– Holder 0.2kg

Dimensions (length × width × height) 65×65×65mm

A) The working range may be reduced by unfavourable environmental conditions

(e.g. direct sunlight).

At 20–25°C

C) The values stated presuppose normal to favourable environmental conditions

(e.g. no vibration, no fog, no smoke, no direct sunlight). Extreme fluctuations in

temperature can cause deviations in accuracy.

D) Only non-conductive deposits occur, whereby occasional temporary conductivity

caused by condensation is expected.

The serial number (11) on the type plate is used to clearly identify your measuring tool.

Assembly

Inserting/changing the batteries

It is recommended that you use alkaline manganese batteries to operate the

measuring tool.

Push the locking mechanism(12) in the direction of the arrow to open the

battery compartment cover(9) and remove the battery compartment cover.

Insert the batteries supplied.

When inserting the batteries, ensure that the polarity is correct according to

the illustration on the inside of the battery compartment.

If the batteries become weak, the laser lines will flash quickly for a few

seconds.

Always replace all the batteries at the same time. Only use batteries from the

same manufacturer and which have the same capacity.

u Take the batteries out of the measuring tool when you are not using it

for a prolonged period of time. The batteries can corrode and self-dis-

charge during prolonged storage in the measuring tool.

Bosch Power Tools 1 609 92A 6GR | (02.02.2021)
