14 | English

Working with the adapter plate (see figuresB–C)

The adapter plate(3) makes it easier to accurately align the measuring tool

with a reference point and enables you to quickly attach and detach the

measuring tool.

The adapter plate(3) can be mounted on the holder(16) or tripod(6).

– Holder: Place the adapter plate with the 1/4" mount(1) on the

screw(13) of the holder and tighten it to secure it on the holder applying

moderate force.

Note: Loosen the locking screw(14) of the holder if you want to change

the position of the measuring tool. If the adapter plate is turned without

loosening the locking screw, the adapter plate can become loose and the

measuring tool can fall off.

– Tripod: Tighten the locking screw of the tripod in the 1/4" mount(1) of

the adapter plate.

Press the measuring tool into the adapter plate(3) so that the locking mech-

anisms of the adapter plate engage in the holes on two sides of the measur-

ing tool. The adapter plate can be fastened to the bottom, back and top side

of the measuring tool.

Check that the measuring tool is firmly secured.

When the adapter plate is mounted on the back, the height of the measuring

tool can be aligned. When it is mounted on the top or bottom, the measuring

tool can be aligned sideways. Turn the fine adjustment screw(2) of the ad-

apter plate to align the laser line with a reference point.

Laser Goggles (Accessory)

The laser goggles filter out ambient light. This makes the light of the laser ap-

pear brighter to the eye.

Maintenance and Service

Maintenance and Cleaning

Keep the measuring tool clean at all times.

Never immerse the measuring tool in water or other liquids.

Wipe off any dirt using a damp, soft cloth. Do not use any detergents or

solvents.

1 609 92A 6GR | (02.02.2021) Bosch Power Tools
