English | 13

measuring tool is held freely in the hand, the laser lines will continuously

flash slowly and the measuring tool will work without automatic levelling.

The laser lines remain switched on, but the two intersecting lines will no

longer necessarily be perpendicular to each other. To make sure that the two

laser lines are still perpendicular to one another, position the measuring tool

at an angle of 90° to the wall.

In case of ground vibrations or position changes during operation, the meas-

uring tool is automatically levelled again. Upon re-levelling, check the posi-

tion of the horizontal or vertical laser line with regard to the reference points

to avoid errors by moving the measuring tool.

Working Advice

u Only the centre of the laser line must be used for marking. The width

of the laser line changes depending on the distance.

Attaching using the holder (seefigureA)

Using the holder(16), you can attach the measuring tool to various objects

up to 10 to 60 mm thick, e.g. to vertical or horizontal boards or pipes.

Loosen the fastening screw(15) of the holder, position the holder in the de-

sired location and retighten the fastening screw.

Place the measuring tool with the tripod mount(8) on the 1/4" screw(13)

of the holder and tighten it to secure it on the holder applying moderate

force. Do not tighten the measuring tool firmly as this could cause damage.

Roughly align the holder before switching on the measuring tool. To do this,

loosen the locking screw(14). Move the measuring tool into a horizontal po-

sition at the required height (with the tripod mount(8) facing down).

Retighten the locking screw.

You can also mount the measuring tool on the holder using the adapter

plate(3).

Working with the Tripod (Accessory)

A tripod offers a stable, height-adjustable support surface for measuring.

Place the measuring tool with the 1/4" tripod mount (8) on the thread of the

tripod (6) or a conventional camera tripod. Tighten the measuring tool using

the locking screw of the tripod.

Roughly align the tripod before switching on the measuring tool.

You can also mount the measuring tool on the tripod using the adapter

plate(3).
