SLOPE FINE ADJUSTMENT MODE / AUTO LEVELING SWITCH OFF

1. Switch the line laser ON. Auto leveling function is activated. Press button

(9) to switch on/o the “slant / slope ne adjustment mode”.

2. It is possible to set the inclination of the horizontal plane along the axis

X and Y.

3. Press and hold button H (7) to set the tilt angle of the horizontal plane

along the axis X down. Press and hold button V(5) to set the tilt angle of the

horizontal plane up.

4. Press button (3) to set the tilt angle along the axis Y.

5. Bi-Bi sound mentions that you’ve reached the limit of slope position.

TO CHECK THE ACCURACY OF LINE LASER

Set up the line laser between two walls, the distance is 5 m.Turn

on the Line Laser and mark the point of cross laser line on the wall.

Set up the line laser 0,5-0,7m away from the wall and make, as described

above, the same masrks. If the dierence {a1-b2} and {b1-b2} is less then

the value of “accuracy” (see spesications), there is no need in calibration.

Example: when you check the accuracy of Line Laser the dierence

is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-

{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.

If the accuracy of Line Laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

TO CHECK THE ACCURACY OF HORIZONTAL BEAM

Choose a wall and set laser 5M away from the wall. Turn on the laser and

cross laser line is marked A on the wall.Find another point M on the hori-

zontal line, the distance is around 2.5m. Swivel the laser, and another cross

point of cross laser line is marked B.

Please note the distance of B to A should be 5m. Measure the distance

between M to cross laser lune, if the dierence is over 3mm, the laser is out

of calibration, please contact with seller to calibrate the laser.
