2 - 2CDC002157D0202
Miniature Circuit Breaker S 200/S 200 M
Technical data
S 200 S 200 M
General Data
Standards IEC/EN 60898-1, IEC/EN 60947-2
UL 1077
IEC/EN 60898-1, IEC/EN 60947-2
UL 1077, CSA 22.2 No. 235
Poles 1P, 2P, 3P, 4P, 1P+N, 3P+N
Tripping Characteristics B, C, D, K, Z
Rated current I
n
0.5 up to 63 A
Rated frequency 50/60 Hz
Rated insulation voltage U
i
250 V AC (phase to ground), 500 V AC (phase to phase)
Overvoltage Category III
Pollution Degree 3
IEC/EN 60898-1
Rated operational voltage U
n
1P: 230/400 V AC; 1P+N: 230 V AC; 2P, 3P, 4P: 400 V AC; 3P+N: 400 V AC
Max. power frequency recovery voltage U
max
1P: 253 V AC; 1P+N: 253 V AC; 2P, 3P, 4P: 440 V AC; 3P+N: 440 V AC;
1P: 72 V DC; 2P: 125 V DC
Min. operating voltage 12 V AC, 12 V DC
Rated short-circuit capacity I
cn
6 kA 10 kA
Energy limiting class (B, C up to 40 A) 3
Rated impulse withstand voltage U
imp
(1.2/50 µs) 4 kV (test voltage 6.2 kV at sea level, 5 kV at 2,000 m)
Dielectric test voltage 2.0 kV (50/60 Hz, 1 min)
Reference temperature for tripping characteristics B, C, D: 30 °C
Electrical endurance I
n
< 32 A: 20,000 ops. (AC), 1,000 ops. (DC); one cycle 2 s - ON, 13 s - OFF
I
n
≥ 32 A: 10,000 ops. (AC), 1,000 ops. (DC); one cycle 2 s - ON, 28 s - OFF
IEC/EN 60947-2
Rated operational voltage U
e
1P: 230 V AC; 1P+N: 230 V AC; 2P, 3P, 4P: 440 V AC; 3P+N: 440 V AC
Max. power frequency recovery voltage U
max
1P: 253 V AC; 1P+N: 253 V AC; 2P, 3P,4P: 462 V AC; 3P+N: 462 V AC;
1P: 72 V DC; 2P: 125 V DC
Min. operating voltage 12 V AC, 12 V DC
Rated ultimate short-circuit breaking capacity I
cu
10 kA 15 kA
Rated service short-circuit breaking capacity I
cs
7.5 kA ≤ 40 A: 11.25 kA
50, 63 A: 7.5 kA
Rated impulse withstand voltage U
imp
(1.2/50 µs) 4 kV (test voltage 6.2 kV at sea level, 5 kV at 2,000 m)
Dielectric test voltage 2.0 kV (50/60 Hz, 1 min)
Reference temperature for tripping characteristics B, C, D: 55 °C; K, Z: 20 °C
Electrical endurance I
n
< 32 A: 20,000 ops. (AC), 1,000 ops. (DC); one cycle 2 s - ON, 13 s - OFF
I
n
≥ 32 A: 10,000 ops. (AC), 1,000 ops. (DC); one cycle 2 s - ON, 28 s - OFF
UL/CSA
Rated voltage 1P: 277 V AC, 60 V DC
2...4P: 480 Y/277 V AC, 110 V DC
1P: 277 V AC, 60 V DC
2...4P: 480 Y/277 V AC, 125 V DC
Rated interrupting capacity 6 kA (AC), 10 kA (DC)
Application Suppl. prot. for general use. Application Codes: TC2, OL0, SC: U1
Reference temperature for tripping characteristic B, C, D, K, Z: 25 °C
Electrical endurance 6,000 ops. (AC), 6,000 ops. (DC); one cycle 1 s - ON, 9 s - OFF
Mechanical data
Housing Insulation group II, RAL 7035 Insulation group I, RAL 7035
Toggle Insulation group II, black, sealable
Contact position indication Marking on toggle (I ON/0 OFF), Real CPI (red ON/green OFF)
Protection degree acc. to EN 60529 IP20
1)
, IP40 in enclosure with cover
Mechanical endurance 20,000 ops.
Shock resistance acc. to IEC/EN 60068-2-27 25 g, 2 shocks, 13 ms
Vibration resistance acc. to IEC/EN 60068-2-6 5 g, 20 cycles at 5…150…5 Hz with load 0.8 I
n
Environmental conditions acc. to IEC/EN 60068-2-30 28 cycles with 55 °C/90-96 % and 25 °C/95-100 %
Ambient temperature -25 ... +55 °C
Storage temperature -40 ... +70 °C
1)
Also fulfilling the requirements acc. to the protection degree IPXXB
