– 8

7 Storage for trigger gun

8 High-pressure hose drum

9 Transport handle

10 Hand crank for hose drum

11 Storage of Plug 'n' Clean detergent bot-

tle with detergent connection

12 Storage for spray lance

13 Storage hook for mains connection ca-

ble

14 Mains cable with mains plug

15 Plug 'n' Clean detergent bottle with

locking lid

16 Transport wheel with wheel cap

17 Trigger gun

18 Lock trigger gun

19 Key to detach the high pressure hose

from the trigger gun

20 Spray lance with pressure regulation

(Vario Power)

Carrying out the most common cleaning

tasks. The work pressure can be stage-

lessly regulated between "Min" and

"Max". You can add detergent when

"Mix" is selected.

In order to adjust the working pressure,

release the lever of the hand spray gun

and turn the spray lance to the desired

position.

21 Spray lance with Dirtblaster

For strong contaminations

———————————————–

Optional accessories

22 Washing brush

Suitable for use with detergents.

23 Rotary washing brush

Suitable for use with detergents.

Especially suitable for cleaning cars.

24 Foam nozzle with detergent container

With powerful foam for effortless clean-

ing.

———————————————–

Not included in the delivery

25 Water supply hose

Use a fabric reinforced water hose with

a commercially available coupling. Min-

imum diameter 13 mm (1/2 inch); mini-

mum length 7.5 m.

Illustrations on fold-out page!

Mount loose parts delivered with

appliance prior to start-up.

Illustration

 Push the wheels into the intake and se-

cure them with the plugs. Align the plug

properly.

Illustration

 Place the bottom holder into the recess-

es and push forward until it audibly

locks in.

 Insert the top holder and push down all

the way.

Illustration

 Press in the storage hook and lock it

into the top position.

You will need the 2 included screws as well

as a Phillips screwdriver PH 2.

Illustration

 Slide the transport handle into the guide

and secure it with 2 screws.

You will need the 2 included screws as well

as a Phillips screwdriver PH 2.

Illustration

 Insert both detergent hoses onto the

hose fittings.

 Install the dosage regulator and con-

nect using 2 screws.

Note: During installation you must

make sure that the tongues of the dos-

age regulator match up with the intend-

ed recesses in the casing.

Before Startup

Attaching the Accessories

Install wheels

Install the storage for trigger gun

Install the storage hook for the mains

connection cable

Install the transport handle

Install the dosage regulator for

detergent

18 EN
