FlexShaft™ Drain Cleaning Machines

999-995-158.09_REV. C

Pre-Operation Inspection

WARNING

Before each use, inspect your Drain

Cleaning Machine and correct any prob-

lems to reduce the risk of serious injury

from electric shock, twisted or broken

cables, chemical burns, infections and

other causes and prevent Drain Cleaning

Machine damage.

Always wear safety glasses, and other

appropriate protective equipment when

inspecting your Drain Cleaning Machine.

1. Clean the machine, including handles

and controls. This aids inspection and

helps prevent the machine or control

from slipping from your grip. Clean and

maintain the machine per the mainte-

nance instructions.

2. Inspect the machine for:

• Proper assembl

y and completeness.

• Any broken, worn, missing, misaligned

or binding parts.

• Presence and readability of the warning

label (see Figure 2).

Figure 2 – Warning Label

It is not recommended to clean glass, ceramic,

porcelain or similar fixtures with the FlexShaft

Drain Cleaners as it may damage the fixture.

Specifications - Acceptable

Battery Powered Drills

Rotational Speed .... 1800 to 2500 RPM

Chuck Size

............. 3/8" or greater

Clutch

..................... With adjustable torque

Switch Type.............

Momentary

Contact

Switch Lock ............ Not equipped with

Drill must carry appropriate certification mark

for the market (CE mark, c()us mark, etc.)

Do not use corded drills, hammer drills or

impact drivers. Use of an inappropriate drill

increases the risk of equipment damage and

personal injury. See Battery Powered Drill

Set-up and Operation section.

Standard Equipment

Refer to the RIDGID catalog for details on e-

quipment supplied with specific drain cleaning

machine catalog numbers.

This machine is made to clean

drains. If properly used it will not damage a

drain that is in good condition and properly

designed, constructed and maintained. If the

drain is in poor condition, or has not been

properly designed, constructed and main-

tained, the drain cleaning process may not be

effective or could cause damage to the drain.

The best way to determine the condition of

a drain before cleaning is through visual in-

spection with a camera. Improper use of this

drain cleaning machine can damage the drain

cleaning machine and the drain. This machine

may not clear all blockages.

Specifications

Model ..........................................................K9-102 K9-204

Drain Capacity (Nom.)

................................1

/4" to 2" (32 – 50 mm) 2" to 4" (50 – 100 mm)

Cable Diameter (without Sheath)................

/4" (6 mm)

/16" (8mm)

Cable Assy. Diameter (with Sheath)

...........

/8" (9.5 mm)

/2" (12.7 mm)

Cable Assembly Length ..............................50' (15.2 m) 70' (21.3 m)

Rotational Speed

........................................Maximum 2500 RPM Maximum 2500 RPM

Drill Attachment

..........................................

/16" Hex (8 mm)

Weight (without Drill/Knocker)

.................. 24.3 lbs. (11.0 kg) 37.3 lbs. (16.9 kg)

Dimension (without Drill)

...........................19.2" × 7.5" × 22.1" 21.1" x 10.8" x 24.2"

(488 mm × 191 mm × 562 mm) (536 mm x 274 mm x 615 mm)

Operating temperature................................20°F to 140°F (-6°C to 60°C)

20°F to 140°F (-6°C to 60°C)

NOTICE

1800-2500

/min

RIDGID.com

Max. 75%
