power tool designation

Power tools allow the following types of work to be per-

formed:

• gouging of niches and openings in walls and oor

structures;

• demolition of building structures (brick- or stone-

work, monolithic concrete, etc�);

• cracking or loosening of various materials or pave-

ments (concrete, asphalt, paving stones, soil with the

inclusion of gravel, ice, etc�);

• chipping of ice, clay, etc�;

• driving of piles and ground rods;

• stamping of different materials�

Some of the above types of operations require special

accessories that are not included in the delivery scope

and not described in this manual�

Power tool

components

Chuck HEX-30

2 Retainer

3 Clamping handle *

4 Additional handle *

5 Ventilation slots

6 On / off switch

7 Lock-on button

8 Tube with lubricant *

9 Wrench *

10 Allen key (5 mm) *

11 Allen key (6 mm) *

12 Plug

13 Lubrication hole

14 Flange wrench *

15 Allen key (4 mm) *

* Optional extra

Not all of the accessories illustrated or described

are included as standard delivery.

Installation and regulation

of power tool elements

Before carrying out any works on the power tool it

must be disconnected from the mains.

Do not draw up the fastening elements

too tight to avoid damaging the thread.

Mounting / dismounting / setting-up of

some elements is the same for all power

tool models, in this case specic models

are not indicated in the illustration.

Additional handle (see g. 1)

Always use the additional handle 4 when operating�

Additional handle 4 may be positioned as deemed

comfortable by the user�

• Loose clamping handle 3 as shown in g. 1.1.

• Place additional handle 4 in desired position (see

g. 1.2).

• Tighten clamping handle 3 as shown in g. 1.3.

Mounting / replacement of accessories (see

g. 2)

• Release the retainer 2 as shown in gure 2.1.

• Install / replace the working accessory in the

chuck 1 (HEX-30) (see g. 2.2). When installing the

working accessory, it is necessary to clear the shank

end preliminarily� Install the accessory only as shown

in the gure: the groove on the accessory must face

the retainer 2�

• Lock the retainer 2 as shown in gure 2.3.

Gloves are to be used when removing

the chisel from chuck 1 (HEX-30), as the

chisel may be dangerously hot after long

work.

•

Initial operating

of the power tool

Always use the correct supply voltage the power

supply voltage must match the information quoted on

the power tool identication plate.

• The power tool is supplied properly lubricated and

ready for use�

• A new power tool needs some time for its parts to

run in before a full load operation� The run-in period

duration is about 5 hours of operation�

• The gear lubrications require a short time to get warm�

Depending on the ambient temperature this period of

time can alter within the range of approximately 15 s

(at ambient temperature of 32°С) up to 2 minutes (at

ambient temperature of 0°С).

Switching the power

tool on / off

[AH15-30 B, AH16-30 B]

Short-term switching on / off

To switch on, press and hold on / off switch 6, to switch

off - release it�

Long-term switching on / off

Switching on:

Push on / off switch 6 and lock it in the position with

lock-on button 7�

Switching off:

Push and release on / off switch 6�
