English

Design features

of the power tool

Vibration protection system

The vibration protection system is design to reduce

vibration impact (during operation) on the operator�

Recommendations

on the power tool operation

Wear thick soft gloves when working to

reduce vibration impact on your body.

• When working, make sure to properly adjust the

working accessory to the material being processed:

not too close to the edge as the power tool will need

to be displaced often, but not too far as the accessory

can get stuck in the material being processed�

• Press the power tool while holding it tightly with both

hands� Do not use excessive force: the energy of the

percussion mechanism is enough for the effective per-

formance�

• Avoid the excessive penetration of the working ac-

cessory into the material being processed (for exam-

ple, when loosening the soil or in the course of the

building structures destruction) as the working acces-

sory may become stuck�

• If the working accessory becomes stuck in the ma-

terial during the operation, do not attempt to free it

with the use of the power tool as a lever as the power

tool can be damaged� Remove the power tool from

the jammed accessory� Continue the operation with

the use of another accessory in order to release the

jammed one� Note: it is strictly prohibited to knock

out the jammed working accessories or to swing

it and to try to extract it with the use of foreign

tools or objects (pieces of pipe, winches, jacks,

etc.).

Power tool maintenance /

preventive measures

Before carrying out any works on the power tool it

must be disconnected from the mains.

Power tool lubrication (see g. 3-4)

[AH15-30 B]

Before starting operation as well as during operating

it is necessary to check oil level through inspection

window of plug 12� Hold the power tool vertically, and

check the oil level (see g. 3.1). If the oil level is lower

than 3 mm from lower point of inspection window, then

necessary to add oil�

• Place the power tool on the at surface.

• Clean with cloth the area around the plug 12�

• Use the wrench 9 to unscrew the plug 12 (see

g. 3.2).

• Add the special oil into power tool from tube 8 as

shown on g. 3.3.

• Use the wrench 9 to screw in the plug 12 (see

g. 3.2).

It's recommended to use special oil from

tube 8�

Using the power tool without oil or with

insufcient oil volume is prohibited as

this may lead to the power tool being

broken down or can void your right for

warranty repair.

[AH16-30 B]

Add grease into the power tool after every 50 hours of

work or if power of impact decreased�

• Place the power tool on the at surface.

• Clean with cloth the area around the plug 12�

• Use the wrench 9 to unscrew the plug 12 (see

g. 4.1).

• Add the special grease from tube 8 into lubrica-

tion hole 13 as shown on g. 4.2. Attention: do

not add grease more than 30g; otherwise the

power tool will be not function properly. It is

recommended that the gears of power tools be

greased with a special lubricant for gears (from

tube 8) - other types of lubricants will harm the

power tool.

• Use the wrench 9 to screw in the plug 12 (see

g. 4.1).

[AH19-30 B]

Add grease into the power tool after every 50 hours of

work or if power of impact decreased�

• Place the power tool on the at surface.

• Clean with cloth the area around the plug 12�

• Use the ange wrench 14 to unscrew the plug 12 (see

g. 5.1).

• Add the special grease from tube 8 into lubrica-

tion hole 13 as shown on g. 5.2. Attention: do

not add grease more than 30g; otherwise the

power tool will be not function properly. It is

recommended that the gears of power tools be

greased with a special lubricant for gears (from

tube 8) - other types of lubricants will harm the

power tool.

• Use the ange wrench 14 to screw in the plug 12

(see g. 5.1).

Using the power tool without grease or

with insufcient grease volume is pro-

hibited as this may lead to the power tool

being broken down or can void your right

for warranty repair.

Cleaning of the power tool

An indispensable condition for a safe long-term exploi-

tation of the power tool is to keep it clean� Regularly

ush the power tool with compressed air thought the

ventilation slots 5�

After-sales service and application service

Our after-sales service responds to your questions

concerning maintenance and repair of your product as
