ENGLISH en

7.5 Setting the torque limitation,

screwdriving, drilling and impact drilling

Fig. F

= Set screwdriving by turning the sleeve

(3)

AND

set the torque (with torque limitation) by

turning the sleeve (2) - intermediate

settings are also possible.

= Set drilling by turning the sleeve (3) (max.

torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

Machines with the designation SB...:

= Set impact drilling by turning the sleeve

(3) (max. torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

7.6 Switching On/Off, setting the speed

Fig. A

Switching on, speed: press the trigger switch (14).

Press in the trigger switch to increase the

rotational speed.

Switching off: release the trigger switch (14). Note:

the noise that the machine makes when it

switches off is due to the design (quick stop)

and has no influence on the function or the

service life of the machine.

7.7 Keyless chuck Fig. G

With a soft tool shank, retightening may be required

after a short drilling period.

Information for machines with the designation

BS 18 LT BL, BS 18 LT BL SE, SB 18 LT BL,

SB 18 LT BL SE

: :

1. The grating sound which may be heard after

opening the chuck is functional and is stopped

by turning the sleeve in the opposite direction.

2. Clamping the tool:

Turn sleeve in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The tool is not yet clamped! Keep

turning the sleeve (it must "click" when

turning), until it cannot be turned any further -

only now is the tool securely clamped.

Cleaning: from time to time, hold the machine

vertically with the chuck facing downwards and

turn the sleeve fully in the direction "GRIP, ZU"

and then turn fully in the direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.8 Unscrewing the chuck Fig. H

Employ the same procedure when attaching the

chuck, except in reverse order.

7.9 Chuck with quick change system (with

BS 18 LT BL Q) Fig. I

To remove: push the interlock ring forward (a),

advance and pull off the chuck forwards (b).

To fit: push the interlock ring forward and move the

chuck as far as the limit stop on the drill spindle.

7.10 Fitting the belt hook (equipment-

specific) / bit depot (equipment-specific)

Fig. J

Fit the belt hook (8) as shown.

Fit the bit depot (7) as shown.

8.1 The machine's multifunctional

monitoring system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds

(continuous beeping). The beeping stops after a

maximum of 30 seconds or when the trigger switch

(14) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1. Battery pack almost empty Fig. A, B (The

electronics protect the battery pack against

damage through total discharge).

If one LED (11) is flashing, the battery pack is

almost flat. If necessary, press the button (10)

and check the LEDs (11) to see the charge level.

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the temperature cut-out.

Leave the machine or battery pack to cool.

Note:

if the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.

Note:

the machine will cool more quickly if you

operate it at idling speed.

3. Metabo safety shutdown: the machine has

SHUT DOWN by itself. If the speed suddenly

drops (for example, if the machine suddenly

seizes or kickback occurs), the machine

switches off. Switch off the machine at the

trigger switch (14). Switch it on again and

continue to work as normal. Try to prevent the

machine from seizing.

Use only original Metabo or CAS (Cordless Alliance

System) battery packs and accessories.

Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.

Fitting the angle drilling attachment Fig. K.

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

8. Troubleshooting

9. Accessories

10. Repairs
