114
ENG
ENGLISH
EXTERNAL CONTROL DEVICE SETUP
*
Real data mapping
00 :
Step 0
A : Step 10 (Set ID 10)
F : Step 15 (Set ID 15)
10 : Step 16 (Set ID 16)
64 : Step 100
6E : Step 110
73 : Step 115
74 : Step 116
CF : Step 199
FE : Step 254
FF : Step 255
24
. Input select (
Command: x
b)
(Main Picture Input)
► To select input source for main picture.
Data Structure
MSB LSB
Transmission [x][b][ ][Set ID][ ][Data][Cr]
External Input Input Number
0 0 0 0 0 0 0 0
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
External Input Data
0 0 0 0 DTV
0 0 0 1 Analogue
0 0 1 0 AV
0 1 0 0 Component
0 1 1 0 RGB
0 1 1 1
HDMI
1 0 0 0
1 0 0 1
1 0 1 0
Input Number Data
0 0 0 0 Input1
0 0 0 1 Input2
0 0 1 0 Input3
0 0 1 1 Input4
25. 3D(Command: x t) (only 3D models)
► To change 3D mode for TV.
Data Structure
Data01 00 : 3D On
01 : 3D Off
02 : 3D to 2D
03 : 2D to 3D
Data02 00 : Top and Bottom
01 : Side by Side
02 : Check Board
03 : Frame Sequential
Data03 00 : Right to Left
01 : Left to Right
Data04 3D Effect(3D Depth) : Min : 00 ~ Max : 14
(*transmit by Hexadecimal code)
*If data1 is 00(3D On), data4 has no meaning.
*If data1 is 01(3D off) or 02(3D to 2D), data2, data3 and
data4 have no meaning.
*If data1 is 03(2D to 3D), data2 and data3 have no
meaning.
Transmission [x][t][ ][Set ID][ ][Data01][ ][Data02]
[ ][Data03][ ][Data04][Cr]
Ack [t][ ][OK][Data01][Data02][Data03][Data04][x]
[t][ ][NG][Data01][x]
26 . Extended 3D(Command: x v) (only 3D models)
► To change 3D option for TV.
Data01 : 3D option
00 : 3D Picture Correction
01 : 3D Depth(Only 2D to 3D)
02 : 3D Viewpoint
03 : 3D Picture Size(Only Plasma TV)
04 : 3D Picture Balance (Only Plasma TV)
05 : 3D Optimization(Only Active type (LCD TV))
Data02 It has own range for each 3D option determined
by Data01.
1) When Data 01 is 00
00 : Right to Left
01 : Left to Right
2) When Data 01 is 01, 02
Data Min: 0 ~ Max: 14
3) When Data 01 is 03
00 : Just Scan
01 : 16:9
4) When Data 01 is 04
00 : Off
01 : On
5) When Data 01 is 05
Data Min: 0 ~ Max: 02
* Refer to ‘Real data mapping’.
Transmission [x][v][ ][Set ID][ ][Data01][ ]
[Data02][Cr]
Ack [v][ ][OK][Data01][Data02][x][v][ ][NG]
[Data01][x]
Data 1 Data 2 Data 3 Data 4
00 O O X
01 X X X
02 X X X
03 X X O
X : don’t care
