ENGLISH

3 Technical Data charger and battery (D)

Battery: Charger:

U = Voltage U1 = Input voltage

C = Capacity f1 = Input frequency

W = Weight P1 = Input power

Ic = Charge current U2 = Charging voltage

t = Approx. charging time (90% full) I2 = Max. charge current

Charging voltage

.............................

20,75 V DC Nc = No. of battery cells

Charging temperature ..

0° - 50° C, 32° - 122° F W = Weight

Max. discharging

temperature.

................................

5° - 50° C, 41° - 122° F

Pay attention to the electrical outlet

voltage! Check the label on the

bottom of the charger!

Recharge battery pack before first use!

4 Function of the Unit

4.1 Overview (A)

1 Battery 6 Bolt.

2 Gear box 7 Reverse speed lever

3 Head housing 8 ON switch

4 Tube fastener adjustment 9 Adapter monoblok 1/4”-1.1/4”

5 Tube fastener (clamp) 10 Adapter euroblok 1/4”-1.1/4”

4.2 Changing the battery (B)

Slide the battery in until you hear it lock into place. Remove the battery by pressing down on the

lock and then pulling the battery out.

Using a battery with at least 4.0Ah is recommended to ensure the optimum processing of pipes

with large diameters. Otherwise, the device’s power might be insufficient and the device will

switch off during the operating cycle.

4.3 Operating (C)

Before carrying out any operations with the machine, first read the general safety

instructions and preparations for start up!

Never reach into the area around the rotating parts!

Always keep one hand on the appliance's handle so that you can operate the On /

Off switch. Do not lock the On switch in place during operation so that you can react

quickly!

 Fasten the tube clamp securely and check that the machine’s anchor bolt is parallel to the

tube to be threaded. The bolt should extend over the end of the tube by approximately 1 or

1.5 cm.

 Choose the threading head according to your needs and mount it in the octagonal coupling

of the machine. Fit the adapter first, when using a 1.1/4” head. For right thread, insert the

threading head ad the front of the machine. For left thread, insert the threading head at op-

posite end of the machine.

 When using the adapter, this should be directly inserted in the octagonal coupling of the ma-

chine on the same in which the threading head has been inserted (right thread: front side;

left thread: opposite side) and secured by its threaded cap.
