POND FILTER

WITH STERILYZING UV-C LAMP

Dear Client, thank you to have chosen GREEN

RESET, the new pond lter with integrated UV-C lamp.

It guarantees high cleaning performances and it is very

easy to use and to clean!

Please, read carefully and save the following

instructions to use in the best way your lter.

SAFETY INSTRUCTIONS

In order to avoid damages to persons/things we

recommend to respect the instructions hereunder

mentioned.

IMPORTANT: always disconnect the power plug and

any other appliances in the pond before touching the

water, before any installation or maintenance work and

even when the appliances are not in use.

2) CAUTION: The Ultraviolet rays are dangerous.

3) This product is a lter with internal UV-C sterilizer for

usage in ornamental ponds. Do not use the appliance

for any other application.

4) Never look directly and touch the UV-C Lamp

when it is on. This can harm eyes and skin. To check

the functioning of the lamp, use only the UV-C light

indicator (g. 1/E).

5) This product is weatherproof but not submersible.

Do not immerse the product in water. If the appliance

falls into water do not attempt to recover it. Disconnect

immediately the power plug.

6) Never use the power cable to lift or move the

appliance.

7) Do not use the appliance for swimming pools or

other application where people are using water.

8) Do not use the appliance if the power cable or plug

are damaged. If the product is damaged it must be

replaced by a specialized after sales centre.

9) Keep children and disabled persons away from this

appliance.

10) Do not open the metal V-band (g. 1/M) or lift the

lter cover when the pump is working. This may cause

a severe hazard.

11) The electrical supply must comply with electrical

data written in the label of the product.

12) If an extension lead is required, make sure it is

waterproof.

13) The lter has a maximum working pressure of 0.4

Bar.

14) Before installing the lter, check that the UV-C light

bulb has not been damaged during transport. If this

is the case return the lter to the dealer and do not

attempt to install it.

15)

This product has been designed to work with water

at a temperature between +4°C and +35°C.

16) If the temperature drops below 4°C, unplug the

power and completely empty the lter. During winter it

is better to remove the lter and store it in a sheltered

place.

17) Do not position the lter in areas liable to ooding

or where it may risk to fall into water.

18) Never operate the appliance without water.

19) Never operate the appliance with liquids different

from fresh water.

20) Never connect the lter to the hydraulic system.

WORKING PRINCIPLES OF GREEN RESET

FILTER

GREEN RESET Filters have been designed to

perform three important stages of ltration, essential

to maintaining pond water clear and healthy:

1 - Mechanical self-cleaning ltration, by special

sponges which block all larger impurities or debris. When

the sponges are obstructed they can be cleaned by the

handle cleaning system without opening the lter.

2 - Biological ltration (Mod. 25 - 40 only), by special

Bio-Balls positioned on the bottom of the lter. Bio-Balls

have a special structure with a wide surface for the

deposit of Bacteria to help maintaining the water healthy.

These special Bio-Balls have to be washed rarely as

each wash removes most of the grown bacterial ora.

3 - Sterilisation by UV-C rays, granted by the special

UV-C lamp.

The water, through the tube which connects the pump

to the Inlet of the lter (g. 1/A), is forced towards the

mechanical ltration compartment. A special header

distributes the water uniformly over the sponges to

ensure maximum efciency over the whole surface.

Then water reaches the grille on the bottom of the lter

compartment and Bio-Balls with bacteria that eliminate

any toxic substances

(Mod. 25 - 40 only)

. The water is

now clean and passes through the UV-C sterilizer that

inhibits algae growth. The water returns to the pond

through the outlet (g. 1/B).

FILTER POSITIONING

The choice in positioning GREEN RESET lter is very

important.

Carefully follow these suggestions:

•

The lter can be placed at ground level or partially

buried. In this case the V-band (g. 1/M) must be kept

at least 10 cm above ground level.

• Do not cover the lter so to avoid overheating.

• Place the lter on a at, stable base, in an adequately

ventilated area, shaded from direct sunlight.

•

Locate the lter vertically at least one metre far from

the edge of the pond and make sure it cannot fall into

water. Verify that there is enough space around the lter

for the cleaning operations.

• Do not make the lter working at pressure over 0.4

bar. Locate the lter so the Inlet (g. 1/ A) and outlet

(g. 1/B) point in the direction of the pond to avoid

useless bends in the connecting pipes.

FIRST INSTALLATION OF GREEN RESET FILTER

• Open the V-band (g. 1/M) and lift the lter cover.

• Remove the sponges.

• Remove the grille under the sponges

(Mod. 25 - 40

only)

• Put the biological ltering material (Bioballs) inside

on the bottom of the lter paying attention to do not

obstruct the central hose (g. 2). Reposition the grille

on the top, xing it correctly. Then position the sponges

(Mod. 25 - 40 only)

• Verify that the O-ring in the top groove of the canister

is positioned in a proper way (g. 3).

• Position the lter cover on the gasket and close the

lter with the V-band paying attention that the O-ring

is still positioned in a proper way. Be careful to do not

pinch your ngers or the power cable.

• Connect the inlet and outlet hoses.

• Verify that the ow switch is in the “FILTER” position

(g. 1/G - 10).

After having done the abovementioned operations,

please proceed as follows:

1. Switch on the pump and let it work for some minutes

in order to verify that everything is functioning and
