– 2
NOTICE
The shorter the hose length and the larger the hose di-
ameter, the higher the pump capacity.
In order to prevent the pump from clogging, use the en-
closed pre-filter (SP 6 Flat Inox) or slide down the inte-
grated pre-filter (SP 7 Dirt Inox) with hose diameters of
less than 1¼ “.
The pump connection is equipped with a plug system
(Quick-Connect).
The unmounted connection nozzle with pump connect-
ing piece is enclosed in the device.
Illustration
To remove the connection nozzle, press the Quick-
Connect (grey button).
Illustration
Screw the pump connecting piece onto the connec-
tion nozzle.
Slide the hose clamp onto the hose.
Slide the hose onto the pump connecting piece and
secure it by means of a hose clamp.
Slide the connection nozzle into the Quick-Connect.
NOTICE
Hoses with a diameter of 1“, 1¼“ and 1½“ can be con-
nected to the pump connecting piece.
To increase the flow volume, the pump connecting
piece can be shortened according to the hose used.
Illustration
Slide the level sensor onto the rail from the top.
Illustration
Fold out or fold in the support legs (SP 6 Flat Inox)
for the pump start.
NOTICE
It is not mandatory to fold out the support legs; a higher
pump capacity is achieved by folding out the support legs.
Folding in the support legs enables the flat vacuuming
of the fluid up to a residual fluid height of up to 1 mm.
Install or uninstall pre-filter (SP 6 Flat Inox).
Slide down or up the pre-filter (SP 7 Dirt Inox).
NOTICE
It is not mandatory to install the pre-filter; a higher pump
capacity is achieved by installing the pre-filter.
The pre-filter pre-filters the feed fluid in order to protect
the pump against excessive soiling.
Disassembly of the pre-filter allows for the flat vacuum-
ing of the fluid up to 1 mm residual fluid height (SP 6 Flat
Inox).
Safely place the pump on a stable surface in the
feed fluid or immerse it using a rope tied to the car-
rying handle.
NOTICE
The suction area must not be blocked by soiling.
In case of muddy ground, place the pump on a brick or
the like.
Ensure that the pump is level.
Do not carry the pump on the cable or the hose.
몇 DANGER
Risk of mortal danger on account of electric shock!
Do not touch feed fluids, the rope attached to the carry-
ing handle as well as objects that are in contact with the
feed fluid (e.g. pipelines extending into the water, rail-
ings, etc.).
Illustration
NOTICE
In order for the pump to draw independently, the fluid
level must be at least 50 mm (SP 7 Dirt Inox) or 7 mm
(SP 6 Flat Inox).
The pump can pump up to a residual fluid height of
35 mm (SP 7 Dirt Inox) or 1 mm (SP 6 Flat Inox).
Illustration
With a low fluid level, possibly drawn air or air that is
present in the pump escapes via the automatic venting
device. In addition, fluid may leak at this spot.
If the pump has suction problems with a low fluid level,
unplug and plug in the mains plug repeatedly in order to
support the suction process.
Illustration
NOTICE
In the automatic mode, the level sensor automatically
controls the pumping operations.
As soon as the level sensor has contact with the rising
feed fluid the pump switches on.
The pump switches off as soon as the level sensor loses
contact with the falling feed fluid and an after-running
time of 15 s has passed.
For switch-on height / switch-off height see the following
table:
NOTICE
Ensure that the pump is level.
Otherwise it can happen that the level sensor does not
lose the fluid contact and the pump runs dry.
Push the level sensor to the desired switch-on
height (contact with feed fluid).
Start up Operation
General
Automatic venting device
Automatic operation
Switch-on points SP 6 Flat Inox SP 7 Dirt Inox
With pre-filter, de-
pending on the po-
sition of the level
sensor
55 - 240 mm 55 - 240 mm
Without pre-filter 1 - 185 mm -
11EN
