38 | English
(38)
Locking screw of the saw table extension
(39)
"Additional parallel guide" fastening set
(40)
Chip ejector
(41)
Dust extraction adapter
(42)
Cable holder
(43)
"Saw table extension" fastening set
(44)
V guide of the parallel guide
(45)
Base plate
(46)
Clamping lever for riving knife
(47)
Positioning pins for riving knife
(48)
Recesses for table insert
(49)
Clamping lever for protective cover
(50)
Guide pin for protective cover
(51)
Clamping handle of the parallel guide
(52)
Additional parallel guide
(53)
Guide rail of the angle guide
(54)
Knurled screw for fixing the angle guide
(55)
"Profile rail" fastening set
(56)
Knurled nut for profile rail
(57)
Lower saw blade cover
(58)
Fastening screw of the lower saw blade cover
(59)
Clamping nut
(60)
Spindle locking lever
(61)
Clamping flange
(62)
Mounting flange
(63)
Tool spindle
(64)
Bevel angle indicator
(65)
Locking knob for all mitre angles
(66)
Mitre angle indicator on the angle guide
(67)
Adjusting plate
(68)
Magnifying glass
(69)
Saw table spacing indicator
(70)
On button
(71)
Cross-head screw for setting the 0° stop
(72)
Screw for bevel angle indicator
(73)
Cross-head screw for setting the 45° stop
(74)
Hex socket screws (5 mm) on the front for adjust-
ing the parallelism of the saw blade
(75)
Hex socket screws (5 mm) on the rear for adjust-
ing the parallelism of the saw blade
(76)
Screw for saw table spacing indicator
(77)
Hex socket screws (5mm) for adjusting the paral-
lelism of the parallel guide
(78)
Screw for parallel guide spacing indicator
(79)
Adjusting screws for table insert
(80)
Bracket for storing the "additional parallel guide"
fastening set
(81)
Holding clip for storing the dust extraction adapter
(82)
Saw blade storage compartment
(83)
Bracket for storing the hex key
(84)
Holding clip for storing the additional parallel
guide
Technical data
Table saw GTS 10 XC GTS 10 XC GTS 10 XC
Article number
3 601 M30 402
3 601 M30 472
3 601 M30 432 3 601 M30 462
Rated power input W 2100 2000 1650
Rated voltage V 220−240 230 110
Frequency Hz 50/60 50/60 50/60
No-load speed min
-1
3200 4200 4200
Starting current limitation ● ● ●
Run-out brake ● ● ●
Overload protection ● ● ●
Weight according to EPTA-Procedure
01:2014
kg 35.0 35.0 35.0
Protection class
/ II / II / II
Dimensions (including detachable parts of the tool)
Width x depth x height mm 810 x 768 x 343 810 x 768 x 343 810 x 768 x 343
Dimensions of suitable saw blades
Saw blade diameter mm 254 254 254
Base blade thickness mm <2.2 <2.2 <2.2
Min. tooth thickness/offset mm >2.4 >2.4 >2.4
1 609 92A 5B8 | (15.07.2019) Bosch Power Tools
