џ I n s t a l l t h e b o l t G i n t o t h e

triangular plate (E)

џ Fix the plate (E) to the base of the

bracket (A) with three screws (D)

using the key (I).

џ Drill a hole in the desk.

џ Install the bracket through the hole in the desktop and secure it to

the underside of the desktop with washer (H) and nut (F).

b) Through hole installation onto the desk:

ATTENTION:

min hole diameter = 10 mm (0.4")in the desk

max hole diameter = 20 mm (0.78")in the desk

desk

Ø10-20 mm

Ø0.4"-0.78"

desk
