Use of extension leads
Only ever use approved extension leads that are
suitable for the power rating of the machine. The
minimum core thickness is 1.5 mm
2
. Whenever
using a reel extension lead, always fully unroll the
lead.
Immediately switch off the machine when:
• Excessive sparking of the carbon brushes.
• Interruption of the mains plug, mains lead or
mains lead damage.
• Defect switch.
• Smoke or stench of scorched isolation.
2. MACHINE INFORMATION
Intended use
The demolition hammer is intended for
demolishing concrete, chiseling off concrete,
grooving and bar cutting.
This machine can only be used with
30mm SDS-Hex chisels.
Technical specifications
Mains voltage 230 V ~
Mains frequency 50 Hz
Power input 1.500 W
Impact rate 1.400/min
Impact energy 50J
Weight 15.6 kg
Sound pressure (L
PA
) 83.88dB(A) K=3 dB(A)
Acoustic power (L
WA
) 105dB(A) K=3 dB(A)
Vibration
Main grip a
h,Cheq
19.67 m/s
2
K=1.5m/s
2
Auxiliary grip a
h,Cheq
15.26 m/s
2
K=1.5m/s
2
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardized test given in
EN60745. It may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level.
•
The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm and organizing your work
patterns.
Description
The numbers in the text refer to the diagrams on
pages 2
Fig. A & B
1. On/off switch
2. Main grip
3. Auxiliary grip
4. Locking pin
5. Tool holder
3. ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug
from the mains.
Mounting and removing the accessory
Fig. B
Do not use blunt drill bits or chisels.
Immediately sharpen or replace blunt
drill bits or chisels.
Mounting
• Apply a few drops of oil into the shaft of the
accessory.
• Pull out the locking pin (4) and turn the locking
pin (4) 180° clockwise or anticlockwise.
• Insert the accessory into the tool holder (5): the
flat side of the accessory towards the side of
the locking pin.
• Pull out the locking pin (4) and turn the locking
pin (4) 180° clockwise or anticlockwise to lock
the accessory.
