MH28539 F08
1-877-288-7722
EV12-110
[12V110AH/20HR]
HENGY ANG RITAR PO
WER CO
.,LTD.
33A
TTERY
CYCLE USE:14.6-14.8V(25 C)
STANDBY USE:13.6-13.8V(25 C)
RECHARGE
V
AL
VE REGULA
TED SEALED LEAD-ACID BA
TTER
Y
Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV12-110(12V110Ah)
Cells Per Unit
6
Voltage Per Unit
12V
Capacity
110Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 30.5 Kg (Tolerance±5%)
Max. Discharge Current
1100A (5 sec)
Internal Resistance
≤5.5 mΩ (Full Charge Condition @25℃)
Terminal
Default F12(M8), F5(M8)&L7 Optional
Maxi. Charging Current
33.0A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
13.6 V~13.8 V @ 25℃
14.6 V~14.8 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
700A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
Length
Width
Height
Total Height
328±2mm (12.9 inches)
172±2mm (6.77 inches)
215±2mm (8.46 inches)
220±2mm (8.66 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit mm
:
F12 Terminal
5
M8
Φ16
328 172
220
215
39.5
265
C3 82.5Ah
C20 110.0Ah
C5 93.5Ah
C10 105.0Ah
ISO 90 01 ISO 14 001 ISO 45 001
MH 28539
BSTXD210316008503EC
F.V/Time 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 265.3 206.5 122.9 67.2 39.9 31.0 24.4 20.7 13.6 11.0 5.73
1.65V 250.6 197.4 118.0 64.9 38.6 30.1 23.7 20.2 13.5 10.9 5.64
1.70V 230.8 184.9 112.7 62.8 37.3 29.2 23.1 19.7 13.3 10.7 5.57
1.75V 211.2 172.1 107.8 60.5 36.0 28.4 22.5 19.2 13.1 10.6 5.50
1.80V 191.2 158.9 103.0 58.2 34.7 27.5 21.8 18.7 12.9 10.5 5.45
1.85V 156.3 131.8 88.7 52.2 31.8 25.4 20.3 17.4 12.1 9.84 5.17
F.V/Time 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 450.9 361.0 223.2 126.3 75.5 59.2 46.8 40.0 26.6 21.7 11.3
1.65V 434.3 350.2 216.5 122.7 73.5 57.7 45.7 39.1 26.4 21.4 11.1
1.70V 407.1 332.9 209.0 119.4 71.5 56.3 44.6 38.2 26.0 21.1 11.0
1.75V 379.4 314.3 201.8 115.8 69.3 54.9 43.7 37.4 25.7 20.9 10.9
1.80V 349.4 294.3 194.9 112.0 67.1 53.4 42.6 36.6 25.4 20.6 10.8
1.85V 290.6 247.7 169.5 101.0 61.9 49.6 39.7 34.2 23.9 19.5 10.2
