Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV6-225(6V225Ah)
Cells Per Unit
3
Voltage Per Unit
6V
Capacity
225Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 32.0 Kg (Tolerance±5%)
Max. Discharge Current
2250A (5 sec)
Internal Resistance
≤2.0 mΩ (Full Charge Condition @25℃)
Terminal
Default F22(M8), F14(M8) Optional
Maxi. Charging Current
67.5A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
6.80 V~6.90 V @ 25℃
7.30 V~7.40 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
1035A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
C3 168.6Ah
C20 225.0Ah
C5 191.0Ah
C10 .0Ah 214
ISO 90 01 ISO 14 001 ISO 45 001
MH 28539
BSTXD210316008503EC
If F22 terminal is selected and the discharge current is more than 0.25C, the threaded terminal of terminal F22 shall not be used in connection, but the lead pole shall be connected.
263
282
Length
Width
Height
Total Height
260±2mm (10.2 inches)
180±2mm (7.09 inches)
263±2mm (10.4 inches)
282±2mm (11.1 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit: mm
If F22 terminal is selected , terminal torque :AP is 5.6 7.9 N m / M8 Stud is 6.6 8.5N m~ * ~ *
F.V/Time 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 397.5 248.8 137.5 81.5 63.4 49.9 42.4 27.9 22.6 11.71
1.65V 380.0 238.9 132.8 78.9 61.5 48.5 41.3 27.6 22.3 11.53
1.70V 355.9 228.3 128.4 76.3 59.8 47.2 40.3 27.2 21.9 11.39
1.75V 331.2 218.2 123.7 73.7 58.0 46.0 39.3 26.8 21.7 11.25
1.80V 305.8 208.6 119.0 71.0 56.2 44.7 38.2 26.3 21.4 11.14
1.85V 253.8 179.6 106.7 65.1 52.0 41.5 35.7 24.7 20.1 10.57
F.V/Time 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 694.8 451.9 258.3 154.5 121.2 95.7 81.8 54.5 44.3 23.1
1.65V 674.1 438.4 250.9 150.3 117.9 93.5 80.0 54.0 43.8 22.7
1.70V 640.8 423.3 244.3 146.2 115.2 91.3 78.2 53.3 43.2 22.5
1.75V 605.0 408.7 236.8 141.7 112.3 89.3 76.5 52.6 42.7 22.2
1.80V 566.5 394.6 229.0 137.3 109.2 87.0 74.8 51.9 42.2 22.0
1.85V 476.8 343.2 206.7 126.5 101.4 81.2 70.0 48.8 39.8 21.0
F22 TERMINAL
