*2271384*

2271384 English 27

3.1.2 Saw trolley (accessory) 2

Grip

;

Throttle trigger

Cutting depth adjustment

Hold-down device

Water tank

(

Water connection

)

Axial adjustment

Throttle cable

Machine cradle

3.2 Intended use

The product described is a gasoline-powered cut-off saw for the wet or dry cutting of asphalt, mineral

construction materials or metals using diamond cut-off wheels or abrasive cut-off wheels. It can be held and

guided by hand or mounted on a saw trolley.

3.3 Recommendations for use

• Use of the wet cutting method is preferable in order to reduce the amount of dust produced when cutting.

By using the self-priming water pump (accessory) you can work without need for a water supply hose.

The water can be drawn, for example, directly from a container.

• Do not cut right through the workpiece in one pass. Move the saw back and forward several times until

it gradually reaches the desired cutting depth.

• To avoid damaging the diamond cut-off wheel when dry cutting, lift the wheel out of the cut for approx.

10 seconds every 30 to 60 seconds while the saw is still running.

• Resharpen a dulled diamond cut-off wheel (i.e. when no diamonds project from the segment matrix) by

cutting with the wheel in a very abrasive material such as sandstone.

• For extensive floor sawing applications, mount the saw on the trolley (accessory).

3.4 Specifications of the cut-off wheels

Diamond cut-off wheels in accordance with EN 13236 are to be used with the product. Synthetic resin-

bonded, fiber-reinforced cut-off wheels in accordance with EN 12413 (straight, not dish-shaped, type 41)

may also be used with the product for working on metals.

The mounting instructions and instructions for use issued by the cut-off wheel manufacturer must be

observed.

3.5 Items supplied

Gasoline-powered saw, operating instructions.

Other system products approved for use with this product can be found at your local Hilti Store or at:

www.hilti.group

3.6 Consumables and wearing parts

• Air filter

• Cord

• Starter

• Fuel filter

• Spark plug
