• Tool set

• Cylinder set

• Mounting screw assy.

• Flange (2)

• Centering bushing 20 mm/1"

4 Technical data

DSH 700-X DSH 900-X

Weight without cut-off wheel, fuel tank

empty

35/14''

11.9 kg 12.0 kg

40/16''

•/• 12.4 kg

Weight with saw trolley, without cut-off

wheel, fuel tank empty

35/14''

42.9 kg 43.0 kg

40/16''

•/• 43.4 kg

Maximum spindle speed 35/14''

5,100 /min 5,100 /min

40/16''

•/• 4,700 /min

Max. rotational speed of the cut-off

wheel

35/14''

5,100 /min 5,100 /min

40/16''

•/• 4,700 /min

Maximum cutting depth 35/14''

125 mm 125 mm

40/16''

•/• 150 mm

Engine type

Single-cylinder, air-

cooled two-stroke

engine

Single-cylinder, air-

cooled two-stroke

engine

Engine displacement

68.7 cm³ 87 cm³

Rated power (ISO 7293)

3.5 kW 4.3 kW

Engine rated speed (ISO 7293)

7500 ± 200 /min 7500 ± 200 /min

Idling speed

2750 ± 250 /min 2750 ± 250 /min

Ignition (type)

Electronically-

controlled ignition

timing

Electronically-

controlled ignition

timing

Electrode gap

0.7 mm 0.7 mm

Spark plug

Manufacturer:

NGK, type: CMR7A

Manufacturer:

NGK, type: CMR7A

Tightening torque for fitting the spark plug

12 Nm 12 Nm

Carburetor

Manufacturer: Wal-

bro; model: WT;

type: 1152

Manufacturer: Wal-

bro; model: WT;

type: 1152

Fuel mixture

API-TC oil 2%

(1:50)

API-TC oil 2%

(1:50)

Tank capacity

0.9 ℓ 0.9 ℓ

Arbor hole, cut-off wheel / diameter of centering collar of

centering bushing (reversible)

20 mm or 25.4 mm 20 mm or 25.4 mm

Minimum flange outside diameter

102 mm 102 mm

Max. cut-off wheel thickness (steel cut-off wheel thick-

ness)

5.5 mm 5.5 mm

Maximum cut-off wheel outside diame-

ter

35/14''

350 mm 350 mm

40/16''

•/• 400 mm

Tightening torque for fitting the cut-off wheel

25 Nm 25 Nm

4.1 Noise information and vibration values

The sound pressure and vibration values given in these instructions have been measured in accordance with

a standardized test and may be used to compare one gasoline-powered saw with another. They may be

used for a preliminary assessment of exposure.
