MEITE шпилька 0.64 мм (23ga) GBA83B00301 Деталировка онлайн

ITEM NO.

PART NO. PART NAME Q'TY

ITEM NO.

PART NO. PART NAME Q'TY

1 B01-01-050250-02 SCREW 4 45 B04-01-040-02 SPRING WASHER 1

2 B04-01-050-02 SPRING WASHER 4 46 AA02F-002A PIN 2

3 AA82A-014A CAP 1 47 AA83B-002A MUZZLE 1

▲4 AA02F-024A GASKET 1 48 AA83B-004A NAIL TROUGH 1

▲5 AA02F-028A AIRPROOF CUSHION 1 49 B04-01-040-02 SPRING WASHER 1

▲6 AA02F-026A SPRING 1 50 B01-06-040100-02 SCREW 1

▲7 B08-012000200 O-RING 1 51 B01-06-040060-02-NL SCREW 2

8 AA83A-003A CYLINDER CAP 1 52 B07-01-040-00 LOCKNUT 1

▲9 B08-028500100 O-RING 1 53 AA63A-013A POTHOOK 1

▲10 B08-022000250 O-RING 1 54 B01-01-040300-02 SCREW 1

11 AA83A-008A ACTIVE VALVE 1 55 AA83A-012A LINK 1

▲12 B08-008000300 O-RING 1 56 AA02F-010A NAIL ORIENT 1

▲13 B08-019000300 O-RING 1 57 AA02F-011A NAIL ORIENT PLATE 1

▲14 B08-015000300 O-RING 1 58 B01-02-030060-02-NL SCREW 2

▲15 AA83B-Y01Al DRIVER 1 59 AA02F-016A PUSHER Ⅱ 2

16 B08-024000250 O-RING 1 60 AA02F-015A PUSHER Ⅰ 7

17 AA83A-004A CYLINDER 1 61 AA02F-017A PUSHER Ⅲ 1

▲18 AA83A-005A BUMPER 1 62 AA02F-018A PUSHER SPRINGⅠ 8

▲19 B08-003000150 O-RING 1 63 AA02F-032A PUSHER SPRINGⅡ 2

20 AA02F-025A

RUBBER PLAIN WASHER

2 64 AA83B-005A NAIL PROPELLENT 1

21 AA83A-001A BODY 1 65 AA83A-014A PUSHER STOPPER 1

22 AA82A-006A GAG 1 66 B04-01-030-02 PLAIN WASHER 1

23 AA83A-009A PLATE 1 67 B01-06-030060-02-NL SCREW 1

24 AA06A-012A VALVE SHIM 1 68 AA83A-018A NOSE PROTECTOR 1

25 AA06A-013A VALVE 1 69 AA02F-001A RUBBER MAT 1

26 AA06A-014B THIMBLE 1 70 B02-030100-02 ROLL PIN 1

▲27 B08-002000150 O-RING 1 71 AA83A-015A RETAINER 1

28 B08-010000200 O-RING 1 72 21336030000 INTERNAL HEX WRENCH 1

29 AA06A-015A VALVE CAP 1 73 AA02F-021A SPRING 1

30 AA06A-016A SPRING 1 74 AA02F-020A LOCKING PAWL 1

31 B03-01-0025-02 E-RING 1 75 B04-02-030-02 PLAIN WASHER 3

32 AA02F-033A SAFETY 1 76 B01-06-030060-02-NL SCREW 3

33 AA02F-031A TORSIONAL SPRING 1 77 AA06A-018A AIR HOSE CONNECTOR 1

34 B05-028125-04 PIN 1 78 AA02F-030A SILENCER 1

35 AA12C-006A

RUBBER SLEEVE

1 79 GG07A SHEATH 1

36 AA02A-014A TRIGGER 1

37 AA02F-029A PIN 1

▲38

B01-01-040060-02-NL

SCREW 2 101 AA83A-Y01A1 CYLINDER CAP SET

39 AA83B-003A MUZZLE COVER 1 102 AA83A-Y05A1 ACTIVE VALVE SET

40 B01-01-050220-02 SCREW 2 ▲103 AA83B-Y02A1 DRIVER SET

41 B04-01-050-02 SPRING WASHER 2 104 AA83A-Y02A1 CYLINDER SET

42 AA83A-016A DRIVER GUIDE 1 105 AA06A-Y11A1 VALVE CAP SET

43 AA83A-018A NOSE PROTECTOR 1 106 AA83B-Y06A1 MAGAZINE SET

44 B01-01-040160-02 SCREW 1
