PREPARATION FOR OPERATION

Join two parts of the lever together, place assembled lever in its socket and secure with lever lock by screwing in the lock.

LIFTING:

Turn the lever clockwise to close the release valve. Secure the vehicle against moving. Place the jack under the vehicle at

appropriate spot (see the user manual of the vehicle for reference). Move the lever up and down to pump until the vehicle is

lifted to desired height.

LOWERING:

Turn the lever to open the release valve (to do so, SLOWLY turn the lever counter-clockwise).

WARNING! : TURN THE LEVER SLOWLY! LOWER A VEHICLE SLOWLY! DO NOT MAKE MORE THAN ONE FULL TURN.

After the vehicle has been lowered, remove the jack from under it.

OPERATION AND MAINTENANCE

REMOVING AIR FROM HYDRAULIC SYSTEM (AIR BLEEDING)

air from the hydraulic system:

Open the release valve.

Remove (unscrew) the plug from the jack cylinder hole.

Firmly pump few times with the lever to remove air from the system.

Close the release valve.

Reinstall the plug.

After air bleeding the jack should operate properly. Otherwise, repeat the procedure as long as necessary.

PREVENTING CORROSION

Protect the jack against humidity. When it comes to contact with moisture, wipe the jack dry and lubricate all visible parts of the jack.

Lubricate pin joints and head screw periodically.

TROUBLESHOOTING

PROBLEM CAUSE

Jack does not

reach its lift

capacity

Jack lowers

under load

Oil spills from

plug

No resistance

in pump move-

ment

Lever goes up

and down, when

under load

Jack does not

raise to its full

height

X X Release valve not fully closed.

X X X

and add clean, hydraulic oil.

drain excessive oil.

X X X

Air in the jack system. Open the release valve

and pump the jack lever a few times. Close the

release valve. Repeat when necessary.

X X X

Valves cannot close due to presence of foreign

body. Flush the valves. Lower the piston rod

and close the release valve. Pull the piston rod

out manually by over 10 cm (4 inches). Open

rod to down position.

TECHNICAL PARAMETERS

Catalogue

number

Static capacity [t] Minimum height [mm] Maximum height [mm] Weight [kg]

11-732 3 85 450 41,7
