Power Unit Assembly
PART
NO.
QTY
DESCRIPTION
PART
NO.
QTY
DESCRIPTION
1
1
Top Nut
19
1
Pump Core (Big)
2
1
O. Ring
20
1
M6 Steel Ball
3
1
Overlay
21
1
Gasket Ring
4
1
Oil Reservoir
22
1
Release Valve
5
1
Oil Plug
23
1
Pump Cylinder (Small)
6
1
Underlay
24
2
Pump Cylinder Gasket Ring (Small)
7
1
Piston Rod
25
2
Pump Cylinder Nylon Ring (Small)
8
1
Bowl Washer
26
1
Pump Core (Small)
9
1
Gasket Ring
27
2
Compression Springs
10
1
Oil Cylinder
28
1
Gasket for Cylinder Cover (Big)
11
1
Oil Cylinder Gasket Ring
29
1
Gasket for Cylinder Cover (Small)
12
2
Filter Screen
30
1
Bead Ring (Big)
13
1
Valve Body
31
1
Bead Ring (Small)
14
5
M5 Steel Ball
32
2
Ball Vale Seat
15
2
Copper Seal Ring
33
2
High Compression Spring
16
1
Pump Cylinder (Big)
34
2
Pressure Adjusting Screw
17
2
Pump Cylinder Gasket Ring (Big)
35
2
Safety Valve Gasket Ring
18
2
Pump Cylinder Nylon Ring (Big)
36
2
Safety Valve Bolt
