11
English
Symbol Meaning
Locked�
Unlocked�
Prohibited�
IPX8
Protection class�
A sign certifying that the
product complies with es-
sential requirements of the
EU directives and harmo-
nized EU standards�
Attention� Important�
Useful information�
Do not dispose of the appli-
ance in a domestic waste
container
Appliance designation
Submersible pumps are designed for pumping clean,
rain and chlorinated water� They can be used for drain-
ing reservoirs and ponds, maintaining a set water level
in the reservoir, organizing water intake from the depth
(in pits, wells, reservoirs) and supplying it to a height�
Appliance components
1 Grid
2 Housing
3 Handle
4 Outlet branch pipe
5 Loop
6 Groove
7 Cable of oating on / off switch
8 Floating on / off switch
9 Fitting *
10 Hose *
11 Hose clamp *
12 Quick change adapter *
13 Quick change tting *
14 Base
15 Base screw
16 Impeller
17 Cap
18 Cap screw
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation of appliance
elements
Before any procedures remove the power cable
from the socket.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Mounting / dismounting / setting-up of
some elements is the same for all appli-
ance models, in this case specic mod-
els are not indicated in the illustration.
The water is supplied from the appliance through
a exible reinforced hose 10 (rubber or plastic, not
included in the delivery set) connected to the out-
let branch pipe 4 through the tting 9. When con-
necting the appliance to steel or plastic pipes, it is
necessary to use a exible hose at least 2 meters
long.
Fitting preparation (see g. 1-3)
Hoses of different diameters as well as quick change
threaded ttings can be connected to the tting 9 (see
g. 1-2).
Using a ne-toothed saw, carefully cut off the unnec-
essary part of the tting 9 (see g. 1-2) and connect ei-
ther a hose or a quick change tting as described below.
Connect the tting 9 to the outlet branch pipe 4 as
shown in the gure 3. Disconnect in the reverse order.
Hose connection (see g. 4)
Put the hose clamp 11 on the end of the hose 10
(see g. 4.1).
Carefully slide the end of the hose 10 onto the t-
ting 9 (see g. 4.2).
Tighten the screw of hose clamp 11 (see g. 4.3).
Hose connection with a quick change adapter (see
g. 5)
Install the quick change adapter 12 on the end of the
hose 10 (see g. 5.1).
Screw the quick change tting 13 onto the tting 9
(see g. 5.2).
When connecting, put the quick change adapter 12
onto the quick change tting 13 and push until it clicks,
as shown in the g. 5.3.
When disconnecting, move the bushing of the quick
change adapter 12 as shown in the g. 5.4 and re-
move the quick change adapter 12 from the quick
change tting 13
Note: do not use a hose having a cross
section under 19 mm (3/4") (for CT35046F)
or 30 mm (1-1/4") (for CT35047), it will in-
crease the load on the appliance and re-
duce its performance.
