INSTRUCTION MANUAL FOR HAND MITRE SAW

Cat. No. 10A035

„Grupa Topex Sp. z o.o. Sp. k.”

Warszawa ul. Pograniczna 2/4

Caution! Before using the saw read this manual and keep it for future reference.

Overview of the saw and its design components

1. Aluminium saw table 7. Two cutting depth adjustment rings and screws

2. Wood-based saw base 8. Adjustable length limiter

3. Saw frame with tensioned blade for general use 9. Angle position indicator

4. Cutting angle setting lever 10 Fixing clamps for processed material

5. Guide rods 11 Central pivoting pin

6. Vertical guides

Before use

Check blade tensioning before operation. If necessary, tension the blade with wing nut (be careful not to over-

tension). When replacing the blade make sure the toothed edge is at the bottom and the teeth are pointed

towards the handle.

Be careful when handling and installing the blade.
