9
ENGLISH
Attaching the Auxiliary Handle (Fig. A, C)
1. Place the auxiliary handle
6
on top of the upper powerhead
pole
19
.
2. Place the handle barrier
17
under the auxiliary handle
6
and
upper powerhead pole
19
so the upper powerhead pole
19
is sandwiched betweentwo handlepieces.
NOTE: Before assembling further, take care to align the
key
34
on the handle barrier
17
with the key slot
35
on the
underside of the upper powerhead pole
19
.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack
8
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
8
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
9
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge
14
, press and hold the fuel gauge
button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Description (Fig. A, E)
WARNING: Never modify the area light. Damage or
personal injury couldresult.
1
Variable speed trigger
2
Lock‑off lever
3
Lock‑off tab
4
Powerhead handle
5
Speed control switch
6
Auxiliary handle
7
Strap mount
8
Shoulder strap (Fig. F)
Intended Use
This powerhead has been designed for powering DeWALT
attachement capable heads. DO NOT use this tool for any job
other than its intendeduse.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Date Code Position (Fig.B)
The date code
13
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020XX XX
Year and week of Manufacture
Wear earprotection.
No hands
Wear slip‑resistantfootwear.
Wear slip‑resistantgloves.
Wear headprotection.
Do not expose the tool to rain or high
humidity or leave
outdoors while it israining.
Switch the tool off. Before performing any maintenance
on the tool, remove the battery from thetool.
Keep bystandersaway.
