1. Loosen the central knob.
2. Remove the cap and the lower support.
NOTE
Do not miss the spring in the support.
3. Put the auxiliary handle in the lower support.
4. Put the cap to the lower support.
5. Put the entire block in its housing on the shaft.
6. Set the auxiliary handle in the comfortable position.
7. Lock the auxiliary handle with the central knob.
3.5 INSTALL THE BATTERY PACK
Figure 5.
WARNING
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the motor stops before
you install or remove the battery pack.
• Read, know, and follow the instructions in the battery
and charger manual.
1. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
2. Push the battery pack into the battery compartment until
the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
3.6 REMOVE THE BATTERY PACK
Figure 5.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
4 OPERATION
IMPORTANT
Before you operate the machine, read and understand the
safety regulations and the operation instructions.
WARNING
Be careful when you operate the machine.
4.1 ON/OFF BUTTON
Push this button to connect and disconnect the electrical
circuit of the machine.
Two green lights on (G): the electrical circuit of the machine
is on (ON). The machine prepares to operate.
NOTE
If you do not use the machine for more than 1 minute, the
machine stops.
Lights off: the electrical circuit is off (OFF).
IMPORTANT
Do not keep your finger on the button when you move the
machine to prevent accidental start.
4.2 SPEED BUTTON
Push this button to increase cutting means speed according to
grass conditions.
Green light on (F) : the brush cutter is in "high speed"
settings.
4.3 START THE MACHINE
Figure 6.
1. Push the on/off button.
2. Push the lock-out button and pull the trigger.
4.4 STOP THE MACHINE
Figure 6.
1. Release the trigger to stop the machine.
4.5 USE THE SHOULDER STRAP
Figure 7.
1. Attach the carabiner to the carrying ring on the pole.
2. Put on the shoulder strap.
3. Adjust the length of the strap so that the carabiner is
about the width of a hand below your right hip.
4.6 OPERATION TIPS
Figure 7.
WARNING
Keep clearance between the body and the machine.
WARNING
Do not operate the machine without guard in place.
Do these tips when you use the machine
• Keep the machine connected to the correctly worn
harness.
• Keep a firm hold with the two hands on the machine
while you operate the machine.
5
English
EN
