English (original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
ATTACHING GRASS DEFLECTOR See Figure 3.
WARNING
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
Remove the battery pack.
Invert the grass trimmer/edger to access the trimmer
head.
Using a Phillips head screwdriver, remove the
preinstalled screw from the trimmer head.
Place the guard on to the trimmer head.
Align the screw hole on the guard with the screw hole
on the trimmer head.
Insert the screw into the trimmer head, fastening the
guard in place.
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second
is sufcient to inict serious injury.
WARNING
Always wear eye protection. Failure to do so could
result in objects being thrown into your eyes resulting in
possible serious injury.
WARNING
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
SHAFT ASSEMBLY See Figure 4.
The attachment connects to the power head by means of
a coupler device.
Set the unit on a flat, level surface.
Loosen the knob (1) on the coupler (5).
Push in the release button (2) located on the lower
shaft (3). Align the release button with the positioning
hole (4) and slide the two shafts together. Rotate the
lower shaft until the button locks into the positioning
hole.
Tighten the knob securely.
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
ATTACHING THE FRONT HANDLE See Figure 5.
Press the auxiliary handle (1) onto the upper shaft so
that the handle is angled toward the rear handle that
allows for comfortable operation.
Slide the auxiliary handle over the metal ring (2) and
ensure the metal ring fits between the slot on the
auxiliary handle.
Align the holes on the auxiliary handle with the holes
on metal ring.
Insert the handle knob (3) through the auxiliary handle.
Tighten until there is no movement in the handle.
OPERATION
Hold the power head with your right hand on the rear handle
and your left hand on the front handle. Keep a rm grip with
both hands while in operation. Power head should be held
at a comfortable position with the rear handle about hip
height. Always operate power head at full throttle. If debris
becomes wrapped around the attachment, RELEASE THE
SWITCH TRIGGER, and remove the debris.
Use the harness when operation.
TO INSTALL BATTERY PACK See Figure 6.
Place the battery pack in the trimmer. Align raised ribs
on battery pack with grooves in the trimmer’s battery
port.
Make sure the latch on bottom of the battery pack
snaps in place and that battery pack is fully seated and
secure in the trimmer before beginning operation.
TO REMOVE BATTERY PACK See Figure 6.
Release the switch trigger and lock-out trigger to stop
the trimmer.
Press the power button to turn off the trimmer.
Press and hold the battery latch button at the bottom of
the battery pack.
Remove battery pack from the trimmer.
STARTING/STOPPING THE TRIMMER See Figure 7.
To start the trimmer, grip the front handle with one
hand while holding the rear handle with your other
hand making sure to depress the lock-out trigger while
squeezing the variable speed trigger.
To stop the trimmer, just release the variable speed
control trigger.
2
