English (original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
SPECIFICATIONS
Type 2401307
Voltage 60V DC
AIR volume 15.3 m³/min
Air speed 225.4 KM/H
Weight (Without
Battery)
2.32 kg
Battery Pack 2918307/2918407
Charger 2918507
Sound pressure
level
83.2dB(A), k:3.0 dB(A)
Sound power level
103 dB(A)
Vibration level
1.23 m/s
2
, k= 1.5 m/s
2
DESCRIPTION
See Figure 1.
1. BLOWER TUBE
2. VARIABLE SPEED TRIGGER
3. BATTERY RELEASE BUTTON
4. CRUISE CONTROL LEVER
5. TURBO BUTTON
ASSEMBLY
UNPACKING
Carefully remove the product and any accessories
from the box.
Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
If any parts are damaged or missing, please call your
Greenworks Tools service centre for assistance.
PACKING LIST
See Figure 2.
Front Blower Tube
Rear Blower Tube
Blower
Operator’s Manual
WARNING
Do not use this product if any parts on the Packing
List are already assembled to your product when you
unpack it. Parts on this list are not assembled to the
product by the manufacturer and require customer
installation. Use of a product that may have been
improperly assembled could result in serious personal
injury.
ASSEMBLING THE BLOWER TUBE
See Figure 3.
WARNING
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from
the tool when assembling parts.
Connect the rear tube (A) to the front tube (B).
Twist clockwise until the tubes lock into position.
See Figure 3-1.
Align either of the grooves (7) in the tube with the
tabs (6) on the blower housing. Push the tube into the
blower housing until the tab engages the grooves.
Turn the tube in the direction of the arrow until
both of the tabs slide into the lock positions.
See Figure 3-2.
TO REMOVE/INSTALL BATTERY PACK
See Figure 4.
TO REMOVE BATTERY PACK
Press and hold the battery release button with firm
grip.
Grasp the trigger handle firmly. Pull the battery pack
out of the handle.
IMPORTANT! The battery pack is not charged when it
place the battery pack in the battery charger and charge.
Make sure to read all safety precautions, and follow the
instructions in the Battery Charger manual.
TO INSTALL BATTERY PACK
Align the tongue of the battery pack with the cavity in
the handle housing.
Insert the battery into the battery opening until the
battery release button (3) locks into place.
Grasp the trigger handle firmly.
Push the battery pack into the handle until both sides
lock. The latch button will click when locked into place.
Do not use force when inserting the battery pack. It
should slide into place and click.
WARNING
Follow these instructions in order to avoid injury and to
• Replace the battery pack or the charger immediately
if the battery case or charger cord is damaged.
• Verify that the switch is in the OFF position before
inserting or removing the battery pack.
• Verify that the battery pack is removed and the switch
is in the OFF position before inspecting, adjusting, or
performing maintenance on any part of the blower.
• Read, understand, and follow the instructions
contained in the section entitled Charging Procedure.
1
