Operating Instructions
10 Indoor Unit
Wireless Remote Controller (optional)
This air-conditioner is equipped with wired remote controller basically. But if you want to be available with
wireless remote controller, you pay for it.
of handling the Remote Controller
• Aim at the signal receptor on the wired remote controller so as to operate.
• The remote control signal can be received at a distance of up to about 7m.
• Be sure that there are no obstructions between the remote controller and the signal receptor.
• Do not drop or throw the remote controller.
• Do not place the remote controller in a location exposed to direct sunlight, or near the heating unit, or any other heat source.
• Block a strong light over the signal receptor with a curtain or etc. so as to prevent the abnormal operation. (ex:electronic quick start, ELBA,
inverter type fluorescent lamp)
Cooling Operation
Auto Operation
Healthy Dehumidification Operation
Flip-up door
(opened)
Heating Operation
Signal transmitter
ON
OFF
CANCEL
AUTO CLEAN
SET
5
1
3
10
9
17
12
14
16
6
4
2
7
11
8
13
15
Operation Mode
•
Cooling Model( ), Heat Pump Model( )
1. Start/Stop Button
Operation starts when this button is pressed.
2. Operation Mode Selection Button
Used to select the operation mode.
3. Room Temperature Setting Buttons
Used to select the room temperature.
4. Indoor Fan Speed Selector
Used to select fan speed in four steps low, medium,
high and Chaos.
5. Jet Cool
Speed cooling/heating operates super high fan speed.
6. Chaos Swing Button
Used to stop or start louver movement and set the
desired up/down airflow direction.
7. On/Off Timer Buttons
Used to set the time of starting and stopping operation.
8. Time Setting Button
Used to adjust the time.
9. Timer Set/Cancel Button
Used to set the timer when the desired time is obtained
and to cancel the Timer operation.
10. Sleep Mode Auto Button
Used to set Sleep Mode Auto operation.
11. Air Circulation Button
Used to circulate the room air without cooling or heating.
12. Room Temperature Button
Used to set the desired horizontal airflow direction.
13. Plasma(optional)
Used to start or stop the plasma-purification function.
14. Horizontal Airflow Direction Control Button
(optional)
Used to set the desired horizontal airflow direction.
15. Reset Button
Initialize remote controller.
16. 2nd F Button
Used prior to using modes printed in blue at the bottom of buttons.
17. Auto Clean(optional)
Used to set Auto Clean mode.
• Remote Controller Model : PQWRHSF0(Heat pump)
PQWRCSF0(Cooling only)
