TYPE OF USE

These devices were designed to vacuum liq-

uids or solids or both, according to the tech-

nical data table from the introduction to this

manual. They were designed only for this

use.

DANGER:

The manufacturer can not be held respon-

sible for any damage due to improper or

incorrect use.

Any other use releases the manufacturer

from liability for harm to persons and/or

property and invalidates any warranty

condition.

IMPROPER USE

Do not use the appliance to:

- Aspirate flammable, explosive, corrosive

and toxic substances.

- Aspirate hot substances.

- Do not use the appliance in liquid suction

mode to suction powder and vice versa.

Do not use the appliance in areas at risk of

explosion.

PREPARING

THE APPLIANCE

Trolley installation

(for models equipped with cart)

- Place the trolley on the ground (1 Fig. 1)

- Place the cover (2 Fig. 1) on the trolley,

setting the support In the plastic (3 Fig. 1)

on the trolley’s rod (4 Fig. 1).

Vacuum cleaner

For appliances equipped with suitable acces-

sories.

- Release the levers (5 Fig. 2) and remove

the cover (6 Fig. 3) complete with the mo-

tor unit.

- Remove the polyester filter (8 Fig. 4).

- Check, if applicable, that inside the de-

vice to be set the paper bag (7 Fig. 4).

- If the paper bag (7 Fig. 4) is not there,

install it, if necessary, acting as follows:

Install the paper bag (7 Fig.5 ) in the noz-

zle (9 Fig. 5) until it passes the banding

(10 Fig. 5)

-

Reassemble the polyester filter

(8 Fig. 4).

- Place the cover back on (5 Fig. 2) and

lock it using the levers.

- Insert, as far as possible, the sleeve (11

Fig. 6) of the suction hose into the nozzle

(12 Fig. 6) on the drum.

- To release the sleeve (11 Fig. 6) press

and hold the button (13 Fig. 6) and then

pull out the sleeve (11 Fig. 6).

- Connect the ergonomic handle (15 Fig. 7)

or the hose (16 Fig. 7) depending on the

model, with the extension (14 Fig. 7).

- Join the two rigid extensions (17-18 Fig.

8), alining the reference points (19-20

Fig. 8), if applicable.

- Attach to the rigid extension (21 Fig. 9)

the desired accessory ( the vacuum noz-

zle, the dust brush, the accessory for tight

spaces, the floor nozzle etc..

NOTES:

For models equipped with ergonomic handle

is possible to adjust the suction force, by act-

ing the selector (22 Fig. 10).

By opening the window (23 Fig. 10) you get a

lower suction force.

Connecting the electrical brush

For devices with socket:

- Lift the shutter (24 Fig. 11).

- Connect the electrical brush’s plug to the

socket (25 Fig. 11) located on the top of

the vacuum (maximum output 200 W).

Manuale AS classic line-8050815_1ed_04-2017.indd 1 18/04/17 12:46
