www.ghibliwirbel.com

Professional Cleaning Machines Since 1968

ENGLISH -

2

Liquid suction

For appliances equipped with suitable acces-

sories.

- Release the levers (5 Fig. 2) and remove

the cover (6 Fig. 3) complete with the mo-

tor unit.

- Remove the polyester filter (8 Fig. 4) if

present.

- Remove the paper bag (7 Fig. 4) if pre-

sent.

- Place the cover back on and lock it using

the levers (5 Fig. 2).

- Insert, as far as possible, the sleeve (11

Fig. 6) of the suction hose into the nozzle

(12 Fig. 6) on the drum.

- To release the sleeve (11 Fig. 6) press

and hold the button (13 Fig. 6) and then

pull out the sleeve (11 Fig. 6).

- Merge the ergonomic handle (15 Fig.

7) or hose (16 Fig. 7) depending on the

model, with the extension (14 Fig. 7).

- Connect the two rigid extensions (17-

18 Fig. 8) by aligning the two reference

points (19-20 Fig. 8).

- Mount on the rigid extension (21 Fig. 9)

the desired accessory,( vacuum nozzle,

floor nozzle etc..)

NOTES:

For models equipped with ergonomic handle

it is possible to adjust the suction force acting

the nut (22 Fig. 10).

By opening the little window (23 Fig. 10) you

get a lower suction force.

USING THE APPLICANCE

- The device is equipped with wheels and

thus can be moved with the proper han-

dles, or it can be pushed with the help of

the handle (26 Fig. 12)

- To lift it up insert your fingers under the

dedicated handle (28 Fig. 13) on the top

of the cover of the single version motor or

lift with the help of two people using the

handles (27 Fig. 12).

Starting up the appliance

- Insert the plug (29 Fig. 14) into the sock-

et.

Single motor

- Press the switch (30 Fig.15) to position

“I” to start the vacuum engine; lights, if

located on the switch will turn on.

Double motor

- Depending on the power required it is

possible to start only one motor by press-

ing the switch (30 Fig. 15) on “I” or both

switches (30 e 31 Fig. 15) if a greater

suction force is required.

Lights, if located on the switch will turn

on.

NOTES:

When the recovery tank is full, the noise

intensity increases and the device can no

longer aspire. Then you must switch off the

device and empty the tank as described in

the relevant paragraphs.

Switching off the appliance

- Push the switches (30, 31 Fig. 15) to the

“0” position to stop the device; the lights,

if any on the switches, will go off.

- Remove the plug (29 Fig. 14) from the

electrical socket.

- Wind up the cable (33 Fig. 16) and hook

it onto its housing (32 Fig. 16).

CLEANING AND

MAINTENANCE

DANGER:

Before performing any maintenance op-

eration, unplug the appliance from the

electrical socket.

Manuale AS classic line-8050815_1ed_04-2017.indd 2 18/04/17 12:46
