www.ghibliwirbel.com

Professional Cleaning Machines Since 1968

ENGLISH -

3

Removing and replacing the paper

dust collection bag (if present)

- Release the levers (5 Fig. 2) and remove

the cover (6 Fig. 3) complete with motor.

- Remove the polyester filter (8 Fig. 4).

- Remove the paper bag for collecting dust

(7 Fig. 4), and replace it as described

above.

- Reassemble all the parts by following the

dismantling process steps in the reverse

order.

Emptying the recovery tank

- Release the lever (5 Fig. 2) and remove

the top (6 Fig. 3) along with the engine.

- Place it on the top of a drain and empty

the liquid in the recovery tank (38 Fig.

18).

- Clean the inside of the tank with running

water and then re-install everything doing

the opposite of the disassembly.

For machines equipped with drain hose

- Release the exhaust tube (36 Fig. 18)

from its base.

- Unscrew the button (35 Fig. 18), re-

move the cap (34 Fig. 18) of the ex-

haust hose (37 Fig. 18) and drain the

liquid in the recovery tank (37 Fig.

18).

For devices with rocking tank

- Release the lever (5 Fig. 2) and re-

move the top (6 Fig. 3) along with the

engine.

- Remove the tank locking device by

acting the lever (40 Fig. 19) if any.

- Lift the tank (39 Fig. 17) with the ap-

propriate lever (41 Fig. 20) until com-

pletely emptied.

- Replace everything doing the oppo-

site of the disassembly.

Daily cleaning

Checking and cleaning the polyester

filter (if present)

- Release the levers (5 Fig. 2) and remove

the cover (6 Fig. 3) complete with motor.

- Remove the polyester (8 Fig. 4) filter.

- Clean the filter (Fig. 21) from the inside

out with a blast of air; the filter can be

washed (Fig. 21) in warm water and must

only be replaced once it is completely

dry. If it is too dirty, replace it.

- Reassemble all the parts by following the

dismantling process steps in the reverse

order.

Cleaning the appliance

- Clean the unit body with a cloth damp-

ened with water or a mild detergent.

- Remove the top, as described above and

clean the inside with running water and

then empty it, as indicated above.

Replace everything doing the opposite of

the disassembly.

DANGER:

Do not wash the appliance using jets of

water.

Periodic checks

Checking the floater

- Remove the top as shown above

- Check If the floater (43 Fig. 22) is In

good condition and if it moves freely in its

space.

Manuale AS classic line-8050815_1ed_04-2017.indd 3 18/04/17 12:46
