GS2200-48 User’s Guide
279
CHAPTER 32
Access Control
This chapter describes how to control access to the Switch.
32.1 Access Control Overview
A console port and FTP are allowed one session each, Telnet and SSH share nine
sessions, up to five Web sessions (five different usernames and passwords) and/or
limitless SNMP access control sessions are allowed.
A console port access control session and Telnet access control session cannot
coexist when multi-login is disabled. See the Command Reference guide for more
information on disabling multi-login.
32.2 The Access Control Main Screen
Click Management > Access Control in the navigation panel to display the main
screen as shown.
Figure 151 Management > Access Control
Table 101 Access Control Overview
Console Port SSH Telnet FTP Web SNMP
One session Share up to nine
sessions
One session Up to five
accounts
No limit
