30 | English
Intended use
The power tool is a stationary machine for cutting in a
straight line with and against the grain in hardwood, soft-
wood, chipboard and fibreboard. Mitre angles of –30° to
+30° as well as bevel angles of 0° to 45° are possible.
It is also possible to saw aluminium profiles and plastic using
the appropriate saw blades.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Scale for spacing between saw blade and parallel
guide
(2)
Scale for spacing between saw blade and parallel
guide when the saw table is pulled out
(3)
Angle guide
(4)
Saw table
(5)
Guide groove for angle guide
(6)
Protective cover
(7)
Anti-kickback pawls
(8)
Table insert
(9)
Parallel guide
(10)
Saw table expansion
(11)
Recessed handles
(12)
Parallel guide storage compartment
(13)
Tilt protector
(14)
Base unit
(15)
Push stick
(16)
Locking lever for setting the bevel angle
(17)
Crank for raising and lowering the saw blade
(18)
Hand wheel
(19)
Safety flap for the on/off switch
(20)
Saw table expansion clamping handle
(21)
Push stick storage compartment
(22)
Stop for 45° bevel angle
(23)
Scale for bevel angle
(24)
Stop for 0° bevel angle
(25)
On button
(26)
Restart button
(27)
Riving knife
(28)
Saw blade
(29)
Angle guide storage compartment
(30)
Cable holder
(31)
Mounting holes on base unit
(32)
Mounting holes
(33)
Tool/anti-kickback pawls storage compartment
(34)
Dust extraction adapter
(35)
Ring spanner (10mm; 13mm)
(36)
Hook spanner/open-ended spanner (10mm)
(37)
"Base unit" fastening set
(38)
"Tilt protector" fastening set
(39)
"Power tool" fastening set
(40)
Riving knife bolt
(41)
Recesses for table insert
(42)
Anti-kickback pawls push button
(43)
Clamping handle for parallel guide
(44)
V guide for parallel guide
(45)
V guide groove on the saw table for the parallel
guide
(46)
Guide groove for parallel guide
(47)
Additional parallel guide
(48)
"Additional parallel guide" fastening set
(49)
Guide rail for angle guide
(50)
Profile rail
(51)
Profile rail wing nut
(52)
Lower saw blade cover
(53)
Fastening screws for lower saw blade cover
(54)
Table insert gripping hole
(55)
Clamping flange
(56)
Saw blade hexagon screw
(57)
Washer
(58)
Mounting flange
(59)
Angle indicator (vertical)
(60)
Locking knob for all mitre angles
(61)
Angle indicator on the angle guide
(62)
Magnifying glass
(63)
Saw table spacing indicator
(64)
Cross-head screw for setting the 0° stop
(65)
Screw for bevel angle indicator
(66)
Cross-head screw for setting the 45° stop
(67)
Hex socket screws (5mm) on the front for adjust-
ing the parallelism of the saw blade
(68)
Hex socket screws (5mm) on the rear for adjust-
ing the parallelism of the saw blade
(69)
Screw for saw table spacing indicator
(70)
Hex socket screws (5mm) for adjusting the paral-
lelism of the parallel guide
(71)
Screw for parallel guide spacing indicator
Technical data
Table saw GTS 254
Article number
3 601 M45 0..
Rated power input W 1800
No-load speed min
-1
4300
Starting current limitation ●
1 609 92A 72F | (13.10.2021) Bosch Power Tools
